Komutatorius Digitus DN-650105, 5 jungtys, 10/100 Mbit/s

Trumpai apie prekę

Prekė: Komutatorius Digitus DN-650105, 5 jungtys, 10/100 Mbit/s. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: Digitus
• Modelis: DN-650105

Manufacturer: Digitus / Product number: 2259024 / Product weight: 0.52kg / EAN: 4016032458814

5-Port Industrial Switch Digitus DN-650105 Fast Ethernet, Unmanaged, Redoable Power

Industrial Fast Ethernet Switch Digitus is designed to work in harsh environments where it is exposed to moisture, temperature changes and vibrations. In the temperature range from -40°C to 85°C, the Industrial Fast Ethernet Switch can be used in the most challenging conditions. Continuous availability is ensured in sectors requiring special protection, such as transport, production, transport and safety monitoring. A simple Plug-and-Play system allows you to quickly connect the Industrial Fast Ethernet Switch to your environment. With Fast Ethernet connectivity, the Fast Ethernet Industrial Switch is therefore a flexible, affordable solution for the industrial environment. Attention! The description of this product has been translated automatically.

Special features

• 5 x 10/100Base-TX Ethernet port
• Automatic cable recognition - Auto-MDI-/ MDI-X function
• Supported standards: IEEE 802.3 10BaseT, IEEE 802.3u 100Base
• IEEE802.3x Flow Control and Back Pressure
• Store-and-forward technology for optimized data transfer

Characteristic

• Automatic speed control and half/full duplex recognition/setting
• mounting plate with
• 1Gbps MAC address memory, 2K
• compact, durable metal housing
• , excellent short-circuit protection
• - Lightning protection and overvoltage protection
• on DIN rail (hat rail) and wall mounting

Technical data

• Auto-Uplink on each port: yes
• Certificate of resistance: IP40
• Further technical data: Extended operating temperature range, -40 °C to +85 °C.
• Detachable terminal block
• Degree of protection: IP40
• Number of Ports: 5
• Ethernet Speed: Fast Ethernet
• Industrial Application: Yes
• Mounting Type: Wall, Mounting Rail
• Product depth: 86 mm
• Number of Ports: 5 Ports
• Number of ports 10/100 MBit/s: 5 x
• Number of Ethernet Ports: 5
• Interface: LAN (10/100 MBit/s), RJ45
• Manufacturer color: blue, blue-lilac, blue, cobalt blue, black
• Maximum ambient temperature: +85 °C
• Minimum ambient temperature: -40 °C
• Operating Voltage: 48 V/DC
• Basic functionality: Unmanaged switch
• Product Width: 118 mm
• Transmission Rate: 10 / 100 MBit/s
• LAN transmission rate: 10 MBit/s, 100 MBit/s
• Port Type: RJ45
• Weight: 360 g
• Product height: 39 mm
• Power supply: from the electrical network, from the electrical network (redundant), through the terminal, through the DIN rail power supply

Scope of delivery

• Industrial Fast Ethernet 5-Port Switch, Quick Start Guide
