IP vaizdo kamera Hikvision DS-2CD2646G2-4LIZSU/PP

Trumpai apie prekę

Prekė: IP vaizdo kamera Hikvision DS-2CD2646G2-4LIZSU/PP. Kategorija: IP kameros.

• Gamintojas: Hikvision
• Modelis: DS-2CD2646G2-4LIZSU/PP

Hikvision DS-2CD2646G2-4LIZSU/PP IP camera

Model: DS-2CD2646G2-4LIZSU/PP

Key features

• Built-in open platform camera provides professional image quality and high-quality input for analytical algorithms
• Supports AI Perimeter Protection, which improves object recognition and reduces false alarms
• Supports wide dynamic range (WDR), backlight compensation (BLC), defog, and electronic image stabilization (EIS)
• Resolution up to 4 MP with the ability to display the image in real time at 25/30 fps. /s, which ensures smoother recordings
• Support for two-way audio transmission and compatibility with the HikCentral Professional platform
• Ability to simultaneously generate five independent video streams with different encoding parameters, supporting up to 20 simultaneous connections
• Supports MicroSD, MicroSDHC and MicroSDXC memory cards up to 512 GB
• Power supply: 12 V DC / 2.125 A or PoE+ (IEEE 802.3at, Type 2, Class 4)
• Built-in 7W speaker for effective outdoor voice communication up to 100m

Technical Specifications Model DS-2CD2646G2-4LIZSU/PP Image Sensor 1/3" Progressive Scan CMOS Maximum Resolution 2560 × 1440 Minimum Illumination Color: 0.005 lx @ (F1.6, AGC on) ), Black and White: 0 lx with IR Shutter Time 1 s to 1/100,000 s Day/Night Mode ICR Angle Adjustment Vertical: 0° to 80° Adjustment Method Manual Adjustment Horizontal Field of View (FOV) 99° to 30.4° Vertical Field of View (FOV) 52.9° to 17.2° Diagonal Field of View (FOV) 117.7° to 34.9° Focus Automatic Iris Type Fixed Iris F1.6 Focal Length 2.8 to 12 mm Perimeter Protection Line crossing, intrusion, entering the area, leaving the area Perimeter Protection Support alarm triggering for specific object types (human and vehicle) Perimeter Protection Dedicated AI model for large-scale perimeter protection, reducing false alarms by 90% compared to conventional AI cameras Metadata Detection Intrusion detection, line crossing detection, area entry detection, area leaving detection Microphone type Electret Number of microphones 2 Microphone frequency response 100 Hz to 20 kHz Microphone sensitivity -32 dBV/Pa Sampling rate 48 kHz Quantization bits 16 bit Speaker impedance 8 Ω Speaker rated power 7 W Total harmonic distortion (THD) 0.05 Speaker sensitivity (1 m, 1 W) 107 dB Maximum sound pressure level 115 dBSPL Speaker frequency response 500 Hz to 6 kHz Speaker unit Dome tweeter Audio algorithm AEC, NS, AGC, DRC Two-way audio Support Network protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, WebSocket, WebSockets Protocol Interface (API) Open Network Video Interface, ISAPI, ISUP 5.0 User Management Up to 32 users, 3 authorization levels: administrator, operator, and user Network Security Password protection, complex password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSS and digest authentication for Open Network Video Interface, RTSP/RTSPS over HTTPS, control timeout settings, security audit log, TLS 1.2 Network Storage MicroSD/MicroSDHC/MicroSDXC card support (up to 512 GB) with network auto-fill and local storage, NAS (NFS, SMB/CIFS); when using high-end Hikvision memory card, memory card encryption and diagnostics are supported Browser Live view without plugin: IE10, IE11 Browser Local service: Chrome 57.0+, Firefox 52.0+ Browser Live view with plugin: Chrome 57.0+, Firefox 52.0+, Safari 12+ Client software iVMS-4200, Hik-Connect, HikCentral Professional Illuminator type Hybrid (IR and white light) Illuminator range White light: up to 20 m, IR: up to 50 m Intelligent Illuminator Yes IR wavelength 850 nm Image parameter switching Support Image settings Saturation, brightness, contrast, sharpness, white balance, adjustable by client software or web browser Image enhancement BLC, HLC, 3D DNR, Defog, EIS White balance Automatic, manual Day/night switching Day, night, Automatic, Schedule, Alarm Trigger Audio Sampling Rate 8 kHz / 16 kHz / 32 kHz / 44.1 kHz / 48 kHz SNR 85 dB Audio Bit Rate 64 Kbps (G.711ulaw/G.711alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32-192 Kbps (MP2L2) / 16-64 Kbps (AAC-LC) / 8-320 Kbps (MP3) Audio Compression G.711a / G.711u / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC / MP3 Audio Type Mono Audio Environmental Noise Filtering Support Alarm 1 input, 1 output Network Interface 1 RJ45 Ethernet port 10M / 100M / 1000M with auto-adaptation Local Storage 8GB eMMC Reset 1 RS-485 1 MicroSD Built-in MicroSD/MicroSDHC/MicroSDXC slot, up to 512GB Power Interface 1 power input, Phoenix connector Basic Events Motion detection, video tampering alarm, alarm input, exception, image quality diagnostics, defocus detection, audio abnormality detection, scene change detection Linked Actions Upload to FTP/NAS/SD, notify surveillance center, send email, trigger alarm output, start recording, audio warning, white flash Smart Events Line crossing detection, intrusion detection, region entrance detection, region leaving detection PoE Power Supply: 42.5V to 57V, 0.447A to 0.6A, max. 25.5W; 12 VDC, 2.125 A, max. 25.5 W Housing Material Metal Dimensions 338 mm × 244.9 mm × 190.1 mm Package Dimensions 420 mm × 280 mm × 316 mm Weight 3.8 kg Packaged Weight 5.07 kg Languages ​​English, Bulgarian, Czech, Danish, German, Greek, Spanish (European), Estonian, Persian, Finnish, French (European), Hebrew, Croatian, Hungarian, Indonesian, Italian, Japanese, Kazakh, Korean, Lithuanian, Latvian, Dutch, Norwegian, Polish , Portuguese (European), Portuguese (Brazilian), Romanian, Russian, Slovak, Slovenian, Serbian, Swedish, Thai, Turkish, Ukrainian, Uzbek, Vietnamese, Traditional Chinese (Taiwan) Color Gray Operating Temperature -30°C to 60°C Operating Humidity 95% or less (non-condensing) Bracket Adjustment Angle -53° to 165° Protection Rating IP67 EMC Class B Safety CB: IEC 62368-1: 2014+A11 Safety CE-LVD: EN 62368-1: 2014/A11: 2017 Environment CE-RoHS: 2011/65/EU Environment WEEE: 2012/19/EU Environment REACH: Regulation (EC) No. 1907/2006 Type H.264 BaseLine Profile / Main Profile / High Profile Type H.265 Main Profile Main Stream 50 Hz: 25 fps /s (2560 × 1440, 1920 × 1080, 1280 × 720) Main stream 60 Hz: 30 fps /s (2560 × 1440, 1920 × 1080, 1280 × 720) Substream 50 Hz: 25 fps /s (704 × 576, 640 × 480) Substream 60 Hz: 30 fps /s (704 × 480, 640 × 480) Fourth stream 50 Hz: 25 fps /s (704 × 576, 640 × 480) Fourth stream 60 Hz: 30 fps /s (704 × 480, 640 × 480) Fifth stream 50 Hz: 25 fps /s (704 × 576, 640 × 480) Fifth stream 60 Hz: 30 fps /s (704 × 480, 640 × 480) Third stream 50 Hz: 25 fps /s (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) Third stream 60 Hz: 30 fps /s (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) Simultaneous live view Up to 20 channels Image overlay LOGO image can be overlaid on video in 128 × 128 pixel bitmap format Bit rate control CBR, VBR Region of interest (ROI) 4 fixed regions for main, sub, tertiary, fourth and fifth streams Scalable video coding (SVC) Support Target cropping Support

• EAN: 6942640560848
• Code: 69520

Additional information regarding offers:

• In the event of any discrepancies between the parameters shown in the "Parameters" section and the "Description" section, the information contained in our title and equipment description shall prevail. Information from the Allegro Product Catalog is added to offers automatically based on EAN numbers ("Parameters" section).
• The photos visible in our offers come directly from the catalogs of manufacturers and distributors. We try to verify them on an ongoing basis with the facts, but we cannot guarantee that they are 100% accurate in every case. Manufacturers often modify the appearance of their products within different production series of the same equipment model (especially batteries and converters! ), without updating the catalog cards. In the case of items visible in the offer photos that are important to you, we will verify the actual condition before shipping the goods.
• The equipment we offer comes from official polish distribution .
