IP kamera Hikvision DS-2CD1T67G3-LIU, 6MP, 2.8 mm objektyvas, IR+LED, iki 50 m

Trumpai apie prekę

Prekė: IP kamera Hikvision DS-2CD1T67G3-LIU, 6MP, 2.8 mm objektyvas, IR+LED, iki 50 m. Kategorija: IP kameros.

• Gamintojas: Dahua Europe
• Modelis: DS-2CD1T67G3-LIU

⭐6 Megapixel IP⭐ Camera

✔ High image resolution 6 Mpix (3200x1800)

✔ Wide camera viewing angle 109°

✔ The infrared diode and the LED used in the camera allow visibility in total darkness up to 50 meters

✔ Motion Detection 3.0 allows intelligent motion detection with object classification

✔ A range of intelligent features, which improve image quality

✔ Built-in microphone recording ambient sounds

✔ Camera with the highest IP67 rating, making it weather resistant

✔ Phone app allows you to view and play back the image

✔ Power supply via PoE

⭐Quality improvement technologies

In addition, the DS-2CD1T67G3-LIU camera has a number of functions to improve image quality such as:

• MD 3.0 Allows you to classify an object (vehicle/human) and filter false alarms
• 3D DNR- Digital Noise Cancellation
• WDR 120dB- Algorithmic image analysis and improvement
• AWB- Automatic white balance
• AGC- Automatic gain adjustment
• BLC- Reverse light compensation
• HLC- Headlamp light compensation

The above-mentioned functions guarantee a great adjustment of the camera settings to the current lighting conditions.

⭐Remote viewing on mobile devices and computers.

Hikvision offers access to free client software for its products. The software is used to preview the image and manage the configuration of cameras.

For users of smartphone there is a Hik-Connect mobile application, and computer owners can use a web browser or the program iVMS-4200 and iVMS-5200

Additionally, it has a function:

• Sharing your device with other users
• playback of video recordings
• Real-time image capture
• remote control of security systems
• handling of e-map
• display of alarm messages
• advanced event search

Technical Specifications

• Image Sensor: 1/2.4" Progressive Scan CMOS
• Maximum Resolution: 6 MP (3200 × 1800)
• Sensitivity: 0.0005 lux (F1.0, AGC ON), 0 lux with IR illuminator on
• Shutter Speed: 1 s ~ 1/100,000 s
• Mechanical Infrared Cut Filter (ICR)
• Position Adjustment:

  Pan: 0° ~ 360°

  Tilt: 0° ~ 180°

  Rotation: 0° ~ 360°

Lens

• Lens Type: Fixed focal
• Available Focal Lengths:

  2.8 mm

  4 mm

• Mount: M12
• Aperture Type: Fixed
• Aperture: F1.0

Field of View for 2.8 mm Lens

• Horizontal: 109°
• Vertical: 60°
• Diagonal: 130°

Field of View for 4 mm Lens

• Horizontal: 89°
• Vertical: 49°
• Diagonal: 105°

DORI Range

2.8 mm Lens

• Detection: 68 m
• Observation: 27 m
• Recognition: 13 m
• Identification: 6 m

4 mm Lens

• Detection: 83 m
• Observation: 33 m
• Recognition: 16 m
• Identification: 8 m

Illuminator

• Smart Hybrid Light
• 850 nm IR Illuminator
• White LED Light
• Illumination Range: Up to 50 m
• Smart Illuminator Control

Video

• Maximum Frame Rate:

  20 fps at 3200 × 1800

  20 fps at 2688 × 1520

  20 fps at 1920 × 1080

• Compression:

  H.265+

  H.265

  H.264+

  H.264

  MJPEG (sub-stream)

• Bitrate: 32 Kb/s ~ 16 Mb/s
• Bitrate Control:

  CBR

  VBR

• ROI – 1 defined region
• Supports SVC for H.264 and H.265

Audio

• Built-in Microphone
• Mono Audio
• Compression:

  G.711 u-law

  G.711 A-law

  G.722.1

  G.726

  MP2L2

  PCM

  AAC-LC

  MP3

• Sampling Rate:

  8 kHz

  16 kHz

• Ambient Noise Reduction

Image Functions

• True WDR 120 dB
• BLC
• HLC
• 3D DNR
• White Balance
• Adjustments:

  Brightness

  Contrast

  Sharpness

  Saturation

  Gain

• Day/Night Mode:

  Auto

  Day

  Night

  Schedule

• SNR ≥ 52 dB
• 4 programmable polygonal privacy masks

Smart Functions

• Motion Detection
• Object Classification:

  Person

  Vehicle

• Image Tampering Alarm
• System Exception Alarms
• Alarm Actions:

  Record video*

  Take snapshot

  Send email

  Upload to FTP server

  Notify monitoring center

  Save to memory card*

* Only applies to versions equipped with a microSD card slot (LIUF).

Network

• RJ45 10/100 Mb/s Ethernet Port
• Protocols:

  TCP/IP

  ICMP

  DHCP

  DNS

  HTTP

  RTP

  RTSP

  RTCP

  NTP

  IPv4

  IPv6

  IGMP

  UDP

  QoS

  FTP

  SMTP

  UPnP

• ONVIF Profile S, G, and T
• ISAPI
• SDK
• Up to 32 users
• 3 user privilege levels
• Up to 6 simultaneous users
• Supports:

  Hik-Connect

  iVMS-4200

Interfaces

• 1 × RJ45 10/100 Mb/s Port
• Built-in Microphone
• microSD/microSDHC/microSDXC card slot up to 512 GB (LIUF version only)
• LIU version does not have a memory card slot

Power Supply

• 12 V DC ±25%
• PoE IEEE 802.3af Class 3
• Maximum Power Consumption:

  6.84 W (12 V DC)

  8.3 W (PoE)

Housing

• Front: Metal
• Body: Plastic
• Bracket: Metal
• Protection Rating: IP67

Operating Conditions

• Operating Temperature: -30°C to +60°C
• Humidity: Up to 95% (non-condensing)

Dimensions and Weight

• Dimensions: 81 × 83.7 × 201.9 mm
• Weight:

  LIU: approx. 440 g

Certifications

• CE
• CB
• RoHS
• REACH
• WEEE
• IP67
