Belaidis prieigos taškas TP-Link EAP650-Desktop, Wi-Fi 6 (802.11ax), Omada

Trumpai apie prekę

Prekė: Belaidis prieigos taškas TP-Link EAP650-Desktop, Wi-Fi 6 (802.11ax), Omada. Kategorija: WiFi maršrutizatoriai ir prieigos taškai.

• Gamintojas: TP-Link
• Modelis: EAP650-Desktop
• Plotis: 175 mm
• Aukštis: 33 mm

EAP650-Desktop

• Wi-Fi 6 AX3000: 574 Mbps in the 2,4 GHz band and 2402 Mbps in the 5GHz band, offering a total of up to 2976 Mbps Wi-Fi†
• Gigabit Ports: Connect multiple devices using 4 gigabit Ethernet ports
• Practical deployment: Support 802.3bt PoE++ and DC power supply (power supply included) for easy and fast deployment
• No installation required: Connecting the device does not require additional installation
• High flexibility: The device can be mounted on a desk or wall
• Advanced features: Omada Mesh, Smooth roaming and Centralized cloud management

TP-Link Omada EAP650-Desktop is a powerful desktop access point with the latest Wi-Fi 6 (802.11ax) standard, designed for business environments and intensive use. The device provides a fast and stable wireless connection in the range of up to 2976 Mb/s, making it ideal for offices, businesses, shops or hotels, supporting a large number of devices without loss of signal quality.

EAP650-Desktop offers support for two bands (2,4 GHz and 5 GHz) and advanced Wi-Fi 6 technologies such as OFDMA and MU-MIMO, which significantly improves network efficiency with multiple simultaneous connections. The device copes well with the transmission of multimedia data, video conferencing and applications requiring high bandwidth.

The access point is equipped with 4 Gigabit Ethernet ports, which allows you to connect multiple wired devices, and port FXS, which extends its use, e.g. in VoIP solutions. Support for PoE++ / PoE power supply and DC power supply makes installation simple and flexible, without the need for additional wiring.

With features such as Omada Mesh and smooth roaming, the network can be easily expanded and device switching between access points is seamless. Central network management, including remote access and monitoring, is made possible by integration with the Omada management system, which simplifies the configuration and maintenance of even extensive installations.

The EAP650-Desktop supports more than 250 devices simultaneously, has advanced security options (WPA3, access control, VLAN, RADIUS), and its aesthetic housing and the ability to mount on a desk or wall make it easy to fit into various workplaces.

It is the perfect solution for businesses that need a stable, efficient, and easy-to-manage professional-grade Wi-Fi network.

Technical specification – TP-Link Omada EAP650-Desktop

HARDWARE FEATURES

Ports

• 4 Ethernet ports 1 Gbps
• 1 port FXS
• 1 Ethernet port supports PoE output:

  802.3at/af using 802.3bt

  or 802.3af Class 2 input using 802.3at

  input

Buttons

• Reset

LED

• Yes

Power supply

• 802.3af/at/bt PoE
• 12 V/1,5 A DC
• PoE output requires 802.3at or 802.3bt PoE power

Power consumption

• 17,3 W (PoE output disabled)

Weight

• 452 g (without mounting stand)

Dimensions (S × G × W)

• 175 × 140 × 33 mm
• 6,9 × 5,5 × 1,3 inch

Antenna

• Internal omnidirectional

  2,4 GHz: 2 × 5 dBi

  5 GHz: 3 × 4,7 dBi

Range

• 140 m²

Assembly

• On desk or wall (mounting kit included)

WIRELESS TRANSMISSION PROPERTIES

Number of simultaneous clients

• 250+

Wireless standards

• IEEE 802.11 a/b/g/n/ac/ax

Frequency of work

• 2,4 GHz and 5 GHz

Transmission speed

• 5 GHz: 2402 Mbps
• 2,4 GHz: 574 Mbps

Wireless transmission functions

• 2×2 MU-MIMO (2,4 GHz and 5 GHz)
• HE160 (160 MHz channel width)
• OFDMA
• Omada Mesh
• Smooth roaming
• Multi SSID (16 SSID, 8 for each band)
• Enabling and disabling SSID broadcasting
• Turning the wireless transmitter on and off
• Network for guests
• Automatic channel selection
• Beamforming
• Speed limitation (based on SSID or client)
• Bandwidth control
• Bandwidth load balancing
• Airtime Fairness
• Transmission power control (power adjustment based on dBm)
• QoS (WMM)
• RADIUS Accounting
• MAC authentication
• Schedule of restarts
• Wireless network schedule and statistics
• Static and dynamic IP address

WIRELESS TRANSMISSION SECURITY

• Authentication with the Welcome Page
• Access control
• Filtering wireless MAC addresses
• Isolation of wirelessly connected clients
• VLAN
• Detection of unauthorized access points
• Support 802.1X
• WPA-Personal
• WPA2-Personal
• WPA3-Personal
• WPA-Enterprise
• WPA2-Enterprise
• WPA3-Enterprise

Power of transmission

• 2,4 GHz: < 20 dBm (EIRP)
• 5 GHz band 1 and 2: < 23 dBm (EIRP)
• 5 GHz band 3: < 29 dBm (EIRP)

MANAGEMENT

• Omada App: Yes
• Centralized management:

  Omada hardware controller

  Omada software controller

  Omada cloud-based controller

• Cloud Access: Yes
• Email Notifications: Yes
• LED Switch: Yes
• MAC Address Access Control: Yes
• SNMP: v1, v2c, v3
• System Journal: Yes
• SSH: Yes
• Browser Management: Yes
• Maintenance-free ZTP configuration: Yes (requires cloud-based Omada controller)

OTHER

Certificates

• CE
• FCC
• RoHS
• IC

Content of packaging

• EAP650-Desktop
• Desk or wall mount kit
• Installation instructions

System requirements

• Microsoft Windows XP
• Microsoft Windows Vista
• Microsoft Windows 7
• Microsoft Windows 8
• Microsoft Windows 10
• Microsoft Windows 11
• Linux

Working environment

• Operating temperature: 0°C – 40°C
• Storage temperature: -40°C – 70°C
• Operating humidity: 10% – 90%, non-condensing
• Storage humidity: 5% – 90%, non-condensing
