Belaidė tinklo plokštė TP-LINK TL-WN722N, USB

Trumpai apie prekę

Prekė: Belaidė tinklo plokštė TP-LINK TL-WN722N, USB. Kategorija: Tinklo plokštės.

• Gamintojas: TP-Link
• Modelis: TL-WN722N

...Wireless long range USB network card...

Product Application - The TL-WN722N wireless USB network card allows you to connect your computer or laptop to a wireless network, providing access to a high-speed internet connection. The wireless transmission speed in the N standard is up to 150 Mbps, thanks to which it is possible to smoothly transmit video or use online games. The QSS button allows you to quickly activate encrypted wireless transmission, protecting your network from external threats.

Wireless transmission speed and range in the N standard - Operating in accordance with the IEEE 802.11n standard, the TL-WN722N reduces signal losses caused by long distances or obstacles (steel or concrete walls of company buildings or apartments). Data transmission at a speed of 54Mbps ensures high work efficiency enabling convenient surfing on the Internet, file sharing, multimedia transfer and making phone calls over the Internet. Clear Channel Assessment (CCA) technology enables automatic avoidance of channel conflicts, increasing wireless transmission efficiency.

External, long-range antenna included - The TL-WN722N network adapter uses a 4dBi antenna with a long transmission range. Depending on external conditions, it is possible to adjust the direction of transmitting and receiving antenna signals. This is more advantageous compared to the use of internal antennas. For more demanding applications, the antenna of the device can be replaced with an antenna with a higher energy gain. This will increase the wireless transmission range of the access point.

QSS button - activation of secure connection - Working in accordance with the Wi-Fi Protected Setup™ (WPS) standard, the TL-WN722N supports Quick Security Setup, allowing users to automatically set up a secured wireless connection by pressing the QSS button. Compared to WEP encryption, the use of the WPS2 encryption method provides greater network security. This solution is not only faster, compared to the traditional configuration, but also much more convenient (no need to remember any password).

WPA/WPA2 - Advanced network protection - WEP encryption is no longer the best protection for Wi-Fi connections against off-grid attacks. The TL-WN722N supports the WI-FI Alliance industry group's WPA/WPA2 encryption standard to protect your WLAN from external threats.

HARDWARE FEATURES

• Ports - USB 2.0
• Buttons - Quick Security Setup (QSS, WPS encryption activation)
• Dimensions -(S x G x W) 93,5 x 26 x 11mm (3,7 x 1,0 x 0,4 inches)
• Antenna Type - Attachable, Omnidirectional
• Antenna Gain - 4dBi

WIRELESS TRANSMISSION PROPERTIES

• IEEE 802.11n, IEEE 802.11g, IEEE 802.11b wireless standards
• Operating frequency 2,400-2,4835GHz
• Transmission speed 11n: up to 150Mbps (dynamic) 11g: up to 54Mbps (dynamic) 11b: up to 11Mbps (dynamic)
• EIRP <20dBm (EIRP, for countries requiring compliance with CE standards) <27dBm (EIRP, for countries requiring compliance with FCC standards)
• Receiver sensitivity 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER
• Ad-hoc wireless and infrastructure modes
• Wireless transmission security 64/128 bit WEP encryption, WPA-PSK/WPA2-PSK
• DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
• Advanced Features WMM,Soft AP (Windows XP/ Vista), PSP X-LINK (Windows XP), Roaming

OTHER

• CE, FCC, RoHS Certificates
• Package Contents Wireless Network Card 4 dBi, Attachable Omnidirectional CD Quick Start Guide
• Windows 7(32/64bit) system requirements. ), Windows Vista(32/64bit. ), Windows XP(32/64bit. ), Windows 2000

Main features of the product TP-Link TL-WN722N

• N wireless data transmission speed up to 150Mbps; smooth video transmission, VoIP calling and online gaming
• High energy gain of external antenna provides greater connection efficiency compared to traditional indoor antennas
• QSS button allows simple compilation of encrypted connection
• 64/128 bit WEP encryption, WPA /WPA2/WPA-PSK/WPA2-PSK(TKIP/AES), IEEE 802.1X compliant
• Attachable antennas allow better regulation of transmission and increase its range
• Easy Setup Assistant software for convenient and quick installation
• Compatible with all devices operating in the 802.11n/b/g standard
• Ad-hoc and infrastructure support
• Compatible with Windows 2000, Windows XP 32/64bit. , Vista 32/64bit. , 7 32/64bit.
