Tinklo komutatorius HIKVISION DS-3E1106P-EI

Trumpai apie prekę

Prekė: Tinklo komutatorius HIKVISION DS-3E1106P-EI. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: Hikvision
• Modelis: DS-3E1106P-EI

SWITCH HIKVISION DS-3E1106P-EI NETWORK

HIKVISION

Switch Hikvision DS-3E1106P-EI

Model: DS-3E1106P-EI Key Features:

• 4 × 10/100 Mbps PoE ports and 2 × RJ45 10/100 Mbps ports
• Total PoE power budget: 60 W
• 802.1Q VLAN support – better segmentation and network security
• PoE Watchdog function – automatic detection and restart of unresponsive cameras
• STP/RSTP support – prevention of loops in the network
• Cable diagnostics for quick fault location
• Long-range PoE transmission up to 300 m
• 6 kV surge protection

Technical specification: ParameterDescriptionHousing materialMetalNet weight0,27 kgGross weight0,77 kgDimensions (W) × H. × D. )121,1 mm × 27,6 mm × 83,1 mmWorking temperature0 °C to 40 °C Storage temperature –40 °C to 85 °CWorking humidity5% – 95% (non-condensing)Relative humidity5% – 95% (non-condensing)Power supply54 V DC,1,2 ATryb installationDesktop, wall-mountedMaximum power consumption65 Power consumption in idle mode1,6 Surge protection6 kVNetwork ports4 × PoE ports 10/100 Mbps,2 × RJ45 10/100 Mbps ports MAC2K address table Switching bandwidth14 Gbps packet forwarding speed10,42 MppsBuffer memory1 MbitStandard PoEIEEE 802.3af,IEEE 802.3atPiny PoEEnd-span Power Supply:1/2 (–), 3/6 (+)PoEPorts 1 to 4Maximum power per port30 WPoE60 Power budget Long-range PoEPorts 1 to 4:up to 300 m (depending on camera and cable quality)VIPPorts 1 to 2 – priority data transferPort isolation 1 to 4:isolation mode for increased securityIsolation policyPorts in one group do not communicate with each otherPoE WatchdogPorts 1 to 4:automatic detection and restart of unresponsive camerasAggregation of linksStatic port aggregationNumber of aggregation groupsMaks. 2Prevention of loopsSTP (802.1D), RSTP (802.1w), disabled by defaultVLANIEEE 802.1QScope ID VLAN1–4094VLANTrunk modes,AccessMaximum number of VLAN32Manage HPOne-click pricing and remote managementHPPP port speed functions,bandwidth usage, PoE consumption, topology, alarms,restart, Long Range mode, remote updateSystem managementWWWDHCP ClientInterfaceSupported (enabled by default)Super IPS IP address:10.180.190.200Central managementHik-Central ProRemote managementHik-Partner ProCable diagnosticsCable detection,short circuits and cable lengthsLLDPIEEE 802.1abMirroring portsSupportedCompatibility EMCEN 55032,EN IEC 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035SafetySecurity 62368-1,CE-LV environmental compatibilityRoHS, REACH, WEEE
