Tinklo jungiklis Planet MGSW-28240F, pagal užsakymą

Trumpai apie prekę

Prekė: Tinklo jungiklis Planet MGSW-28240F, pagal užsakymą. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: Planet
• Modelis: MGSW-28240F

Planet MGSW-28240F on request

Planet

10 Gbps fiber ports and multiple triple-speed fiber ports for fast networking

The PLANET MGSW-28240F L3 24-Port 100/1000BASE-X SFP+ 4-Port 10G SFP+ Metro Ethernet Switch is specifically designed for service providers and enterprises to provide high-speed networking over longer distances. Its SFP+ and SFP fiber ports can be connected to a variety of fiber optic and Ethernet cables to extend switching functionality across the network. The MGSW-28240F is capable of providing a non-blocking switch structure and bandwidth of up to 158Gbps in the temperature range of -10 to 60 degrees C without packet loss and cyclic redundancy control (CRC) errors. This greatly simplifies the task of upgrading an enterprise LAN to meet the growing demand for bandwidth.

Flexible and extensible fiber-optic Ethernet solution

10G Ethernet is a big leap in the evolution of Ethernet. Each of the 10G SFP+ ports on the MGSW-28240F supports triple speed SFP transceivers, 10GBASE-SR/LR, 2500BASE-X and 1000BASE-SX/LX. With the ability to support 4 ports, 10Gb/s and up to 24 ports of 1Gb/s/2,5Gb/s fiber Ethernet, an administrator can now flexibly select the appropriate SFP and SFP+ transceivers depending on the transmission distance or transmission speed required for efficient network expansion. The MGSW-28240F provides wide bandwidth and powerful processing capacity.

Interface design with front access

The Metro Ethernet switch features a user-friendly design with front-end access to help technicians increase wiring and installation efficiency, while in traditional design, the power socket, console port, and even some expansion modules were always placed on the back of the product. When technicians install or maintain an older switch model in a rack, they need to watch out for other surrounding devices online because the back of the product cannot be seen clearly. With a front-access design, technicians can avoid clutter with other nearby devices.

Support for Layer 3 routing

The MGSW-28240F enables an administrator to conveniently increase network performance by manually configuring IPv4/IPv6 VLAN Layer 3 static routing and OSPFv2 (Open Shortest Path First) automatic IPv4 settings. OSPF is an internal dynamic routing protocol for a standalone system based on the state of the link. The protocol creates a link state database by exchanging link states between Layer 3 switches and then uses the Shortest Path First algorithm to generate a route table based on that database.

Cybersecurity network helps minimize security risks

The MGSW-28240F is equipped with advanced cybersecurity protections to counter threats and cyber attacks. It supports SSHv2, TLSv1.2 and SNMPv3 protocols, providing strong protection against advanced threats. The MGSW-28240F switch cybersecurity feature serves as a key data transmission point for critical customer devices in the business network, protecting switch management and increasing mission-critical network security without the additional cost and effort of implementation.

Redundant ring, fast recovery for critical network applications

The MGSW-28240F switch supports redundant ring technology and features a strong, fast self-healing function to prevent interruptions and intrusions from outside. It includes advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching) technology, spanning tree protocol (802.1s MSTP) and redundant power system in customer industrial automation network to increase system reliability and uptime in harsh factory conditions. In a simple Ring network, the data link restore time can be as long as 10 ms.

Redundant AC and DC power supply for continuity of operation

The MGSW-28240F features a 100~240V AC power supply and a dual 36~60V DC power supply used as a redundant power source to ensure its continuous operation. Its redundant power system is specifically designed to meet the demands of high-tech facilities that require the highest power integrity. Moreover, with 36~60V DC power supply implemented, MGSW-28240F can be used as a telecommunication device and placed in almost any harsh environment.

Digital input and digital output for external alarm

The MGSW-28240F helps network administrators effectively manage unexpected network situations by providing digital input and digital output for an external front panel alarm device. The digital input can be used to detect and record the status of external devices, such as a door intrusion sensor. The digital output can be used to send alarms whenever the MGSW-28240F has a port connection or power failure.

Ability to work in Layer 2

Supporting both IPv6 and IPv4 protocols, the MGSW-28240F helps data centers, campuses, telecommunications companies and others enter the IPv6 era with the lowest investment, as network devices do not need to be replaced or renovated when an IPv6 FTTx edge network is created.

Powerful network security

The MGSW-28240F offers a comprehensive access control list (ACL) in layers 2 through 4 to ensure edge security. It can be used to restrict network access by rejecting packets based on source and destination IP addresses, TCP/UDP ports, or defined common network applications. The protection mechanism also includes port-based and MAC-based authentication of 802.1X users and devices. Thanks to the private VLAN function, communication between edge ports may be prevented to ensure user privacy.

Advanced IP network protection

The MGSW-28240F also provides DHCP Snooping, IP Source Guard and Dynamic ARP Inspection features to prevent IP snooping attacks and reject ARP packets with an invalid MAC address. Network administrators can now build highly secure enterprise networks with significantly less time and effort than before.

Excellent motion control

The MGSW-28240F is equipped with advanced traffic management and QoS capabilities that streamline the calling services provided by telecommunications companies and internet service providers. QoS features include Layer 4 traffic classifiers and bandwidth constraints, which are particularly useful for multi-tenant units, multi-branch units, telecommunications company applications and network service providers. They also enable the industrial environment to take full advantage of limited network resources and guarantee the best performance in VoIP and video conferencing.

User-friendly and efficient switch management

For efficient management, the MGSW-28240F is equipped with command line management interfaces, Web and SNMP.

• The built-in web-based management interface offers easy-to-use, platform-agnostic management and configuration.
• Text management can be accessed through Telnet and the console port. It offers Cisco-like commands so users don't have to learn new commands from these switches.
• For standards-based monitoring and management software, the device offers an SNMPv3 connection that encrypts packet contents during each session to ensure secure remote management.

What’s more, the MGSW-28240F offers secure remote management with support for SSHv2, TLSv1.2 and SNMPv3 connections that encrypt packet content during each session.

Intelligent SFP diagnostic mechanism

The MGSW-28240F supports SFP-DDM (Digital Diagnostic Monitor) function, which greatly helps the network administrator to easily monitor SFP parameters in real time, such as optical output power, optical input power, temperature, laser polarization current and transceiver supply voltage.

• Redundant Power Supply: Yes
• Managed: Yes
• Main Port Type: SFP / SFP
• Main Port Bandwidth: Gigabit Ethernet
• PoE Support: No
• Quantity per Master Pack: 5 pcs
• Height: 4.42 cm (1.74 inches)
• Width: 44.37 cm (17.47 inches)
• Depth: 20 cm (7.87 inches)
• Weight: 2.935 kg (6.47 lbs)
• Manufacturer Information: PLANET TaiwanNew Taipei City2314110F No. 96 Minquan Rd. Xindian Dist. New Taipei City Taiwan sales@planet.com.twwww.planet.com.tw +886222199518
• EU Responsible Person Information: Konsorcjum FEN Sp. z o.o.PolskaPoznań60-415Czarnkowska 13Konsorcjum Fen sp. z o. o.gpsr@fen.plhttps://b2b.fen.pl/+48 616690700

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer	Planet
Parametry	Number of ports	24
Parametry	LAN port operating standard	10/100/1000 Mbps
Parametry	EAN (GTIN)	4711213689666
Parametry	Manufacturer code	MGSW-28240F
