Stebėjimo kamera PTZ Uniview IPC6424SR-X25-VF-B, greito veikimo

Trumpai apie prekę

Prekė: Stebėjimo kamera PTZ Uniview IPC6424SR-X25-VF-B, greito veikimo. Kategorija: IP kameros.

• Gamintojas: Uniview
• Modelis: IPC6424SR-X25-VF-B

IP camera with very good high resolution transducer. This makes it ideal for monitoring systems where identification of persons or vehicles is required.

The built-in infrared illuminator allows you to work at night, while the zoom lens with a large viewing angle adjustment range allows for optimal cropping of the image in all conditions. The range of the illuminator given by the manufacturer depends on environmental conditions (air transparency, environment, wall color, i.e. scene reflection coefficient).

PoE power capability, according to the 802.3at standard, makes the device even more versatile and easier to install.

For several IP cameras operating at a resolution of ≥ 1920 x 1080, we recommend using a network with a bandwidth of 1Gb / s.

Standard: TCP/IP

Transducer: 1/2.8" Progressive Scan CMOS

Matrix Size: 4 Mpx

Resolution:

2688 x 1520 - 4 Mpx ,

2560 x 1440 - 3.7 Mpx ,

1920 x 1080 - 1080p

1280 x 720 - 720p

Lens: 4.8 ... 120 mm

Viewing angle:

• 52 ° ... 2.7 ° (manufacturer's data)
• 52° ... 3.1° (our tests)

Optical Zoom: x 25

Digital Zoom: x 16

IR illuminator range: 100 m

Video output: 1 Vpp / 75 Ω - BNC plug

Rotation speed at presets:

• 240 °/s (level)
• 200 °/s (vertical)

Rotation speed (manual control):

• 0.1 °/s ... 200 °/s (level),
• 0.1 °/s ... 120 °/s (vertical)

Horizontal rotation range: 360 ° - continuous

Vertical rotation range: -15 ° ... 90°

Number of presets: 1024

Setting Traffic Routes: 16

Image compression method: Ultra H.265 / H.265 / H.264 / MJPEG

Emergency Inputs / Outputs: 2 / 1

Audio:

• Audio Input
• Audio Output
• Support two-way audio
• Sound detection
• Noise reduction

Main stream transmission speed: 1 ... 30 fps @ 4 Mpx

Network Interface: 10/100 Base-TX (RJ-45)

WEB Server: Built-in

Max. Number of users online: 32

Memory card slot: Support Micro SD cards up to 256GB (local storage possible)

Access from mobile phone:

Access via cloud (P2P)

• Android: Free EZView App
• iOS (iPhone): Free EZView App

Default IP address:

DHCP or 192.168.1.13

Default administrator login / password: admin / 123456

Web access ports: 80, 554

Access ports via PC app:

Port: 80 or cloud access (P2P) - PC: Free EZStation App

Mobile application access port: 80

Port ONVIF: 80

Selected functions:

• WDR - 120 dB - Wide range of lighting dynamics
• 2D-DNR, 3D-DNR - Digital noise reduction in the image
• ROI - improving the quality of selected image fragments
• F-DNR (Defog) - Noise reduction associated with precipitation
• BLC/HLC - compensation of background light / strong light
• Day/night mode
• ICR - Mechanical Infrared Filter
• Automatic white balance
• Customizable Privacy Zones - 24
• Motion detection
• Indication of sabotage
• Image rotation and mirroring
• Adaptive adjustment of IR illuminator power to lens zoom and outdoor lighting brightness
• Intelligent image analysis : line crossing, intrusion, area entry/exit detection, false alarm filtering based on person and vehicle recognition, face detection - supports 4 types of facial attribute extraction, counting people entering and leaving a given area, estimating the size of the accumulated crowd
• Intelligent Object Tracking

Housing: Speed Dome, Metal + Plastic

Color: White + Black

Protection class: IP67

Vandal-proof: IK10

Power supply:

• PoE (802.3at)
• 12 V DC / 3 A (power supply included)

Power Consumption: ≤ 21 W

Operating temperature: -40 °C ... 70 °C

Weight: 4.02 kg (with handle)

Dimensions: Ø 166 x 280 x 378 mm (with handle)

Supported languages: Polish, English, Czech, French, Spanish, Dutch, German, Portuguese, Slovenian, Hungarian, Italian

Manufacturer / Brand: UNIVIEW

Specifications
