Maršrutizatorius GL INET, 2.4 GHz, Ethernet, ESP32, Thread, BLE 5.0, PoE, IoT

Trumpai apie prekę

Prekė: Maršrutizatorius GL INET, 2.4 GHz, Ethernet, ESP32, Thread, BLE 5.0, PoE, IoT. Kategorija: WiFi maršrutizatoriai ir prieigos taškai.

• Gamintojas: GL.iNet
• Modelis: 569496806

SKU: GL-S20-POE

Key features:

✅ Dual-core ESP32-S3 chip: reliable 24/7 network performance

✅ Thread 1.3 + BLE 5.0: Compatibility with modern IoT devices

✅ Wi-Fi 2,4 GHz: stable cable-free access

✅ Ethernet 10/100 Mbps: fast integration with LAN or monitoring systems

✅ Wi-Fi failover mode ↔ LAN: smooth switching in case of failure of one link

✅ PoE power supply: one cable, less problems

✅ Low power consumption: less than 3W at DC and less than 7W at PoE

✅ Compact design: easy installation in tight spaces

✅ Resistance to stress conditions: -20 °C and +70 °C

What is a Thread Border Router and Why Does It Matter?

➡️ The GL-S20 acts as a Thread Border Router – essentially a bridge between your local IP network (LAN) and devices on a Thread network.

You can connect sensors, locks, thermostats, or smart switches into a unified, self-healing IoT network that automatically restores connectivity if one component fails.

Extremely efficient

The GL-S20 router has an efficient ESP32-S3 chip, supported by the additional ESP32-H2 coprocessor to support Thread communication.

✔ Lower energy consumption

✔ Stability with a large number of connected devices

PoE, Wi-Fi and failover

The GL-S20 router offers full flexibility of power supply and connections.

• Connection via USB-C power supply
• Using Power over Ethernet (PoE)
• Use of Wi-Fi 2,4 GHz

What’s more, the device automatically switches between links – if one falls, the other continues to work.

Building automation and smart home

The GL-S20 router was created for integrators who need a simple yet reliable component to build an IoT network.

It will work in:

• dwellings
• single-family homes
• offices
• hotels
• production halls

Future in line with standards

The router supports the latest version of the Thread 1.3 protocol, which becomes the foundation for standards such as Matter – supported by m.in. by Apple, Google and Amazon.

▶ GL-S20 not only connects devices, but is ready for the next generation of smart home equipment.

Specification

• Processor: ESP32-S3, dual-core, 240 MHz
• Memory: 512 KB SRAM + 8 MB PSRAM
• Flash memory: 16 MB
• Supported protocols: Thread 1.3 (mesh networking for IoT), BLE 5.0 (Bluetooth Low Energy), Wi-Fi 2.4 GHz – 802.11b/g/n
• Wi-Fi speed: up to 150 Mbps (2.4 GHz)
• Ethernet speed: 10/100 Mbps
• LED: Power (power supply), IoT (device status), Network (network connection)
• Power port: USB Type-C, 5V/1A
• PoE support: IEEE 802.3af (power over Ethernet)
• Energy consumption: < 3 W (DC power supply), < 7 W (PoE)
• Work: 0 °C ~ 40 °C
• Storage: -20 °C ~ 70 °C
• Dimensions: 76 × 76 × 25 mm
• Mass: approx. 63 g

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer	GL.iNet
Parametry	Mode of operation	Router
Parametry	Wireless operation standard	other
Parametry	Internal modem	no modem
Parametry	LAN port operating standard	10/100 Mbps
Parametry	EAN (GTIN)	5908066537322
Parametry	Manufacturer code	569496806
Parametry	Model	569496806
Parametry	The highest standard supported	other
