Lauko IP vaizdo kamera 4MP su IR50, HiLook IPCAM-B4-50IR, suderinama su HIK programėle

Trumpai apie prekę

Prekė: Lauko IP vaizdo kamera 4MP su IR50, HiLook IPCAM-B4-50IR, suderinama su HIK programėle. Kategorija: IP kameros.

• Gamintojas: HiLook
• Modelis: IPCAM-B4 50IR

IP / 4Mpx / 4mm / IR50m / IP67 / H.265+ / PoE / Application

IPCAM-B4-50IR is a high-quality IP camera with 4MP resolution, dedicated to small and medium-sized monitoring installations in locations such as home, business or store.

The camera has a built-in IR infrared illuminator from high power (range up to 50m)

Most important features:

• High image resolution in 4MPx 2K - 2560x1440 pixels
• Infrared illuminator with a range of up to 50m
• Tight outer casing IP67
• Convenient power supply via PoE
• Remote access via the HikConnect app
• Easy installation and operation

• Converter: 1/3” 4MPx CMOS
• Recording resolution: 2560×1440 @20FPS
• Lens: wide-angle 4 mm
• Recording angle: ~83,2°
• Image compression: H.265, H.264+, H.264, MJPEG
• Wide dynamic range: True WDR 120dB
• Digital Noise Cancellation: Yes - 3D DNR
• Night mode: Yes - infrared
• Infrared range: up to 50 m
• P2P(cloud) support: Yes - a feature that allows remote access without port forwarding and public IP address
• Support in Hik-Connect: Yes
• Remote support: iVMS-4200, WEB interface, Application
• Assembly: external or internal
• Power Supply: 12V orPoE
• Protection class: IP67

The camera is sold without a 12V power supply. Compatible power supply is available at auction No. 16007754465.

HiLook monitoring systems can be controlled, configured and operated using the intuitive mobile application HiLook App for smartphones and tablets and the iVMS-4200 program for PCs. Thanks to this, the user has constant control and supervision over the monitored space from anywhere on earth with access to the network. The application and program allow you to:

• live image preview
• remote playback of recordings
• creating motion detection scenarios and rules
• control of rotary cameras
• receiving notifications about events within the system

The application uses the P2P cloud, so that the system does not have to have redirected ports on the router.

The IPCAM-B4-50IR is equipped with an extremely efficient IR illuminator, generating a light beam with an operating range of up to 50m. Thanks to such a powerful illuminator, the camera effectively captures all objects even in complete darkness.

The camera has a built-in motion detection algorithm - when detecting moving objects on stage, the camera can send an alarm notification to the program and application.

What’s more, recording in motion detection mode, the camera allows you to save a very large amount of space on the hard drive, which positively affects its lifespan.

The camera uses an efficient image compression standard, designated H.265. This standard is a direct successor to the popular H.264 technology and allows for almost double the bandwidth load. This translates into significant space saving on the hard disk and extending the archiving time of recordings on the disk.

Camera

• Image Sensor: 1/3" CMOS Progressive Scan
• Transmission Standard: IP
• Maximum Resolution: 4MP @2560x1440
• Sensitivity: Color: 0.01 Lux
• Shutter Speed: 1/3 s to 1/100,000 s
• Slow Shutter Mode: Supported
• Lens: 4 mm
• Field of View (Horizontal): Horizontal FOV 83.2°, Vertical FOV 45.5°, Diagonal FOV 98.3°
• Pan/Tilt/Rotate Adjustment: Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360°

Illuminators

• IR Range: Up to 50m (164 ft)
• IR Wavelength: 850 nm

Video Compression

• Video Compression: Main Stream: H.265+/H.264+/H.265/H.264 Sub-stream: H.265/H.264/MJPEG
• H.264: Baseline Profile/Main Profile/High Profile
• H.264+: Main Stream
• H.265: Main Profile
• H.265+: Main Stream
• Video Bitrate: 32 Kbps to 8 Mbps

Smart Features

• ROI (Region of Interest): 1 fixed region for two streams


• Main Stream - Max. Frame Rate: 50Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720) 60Hz: 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720)
• Sub-stream - Max. Frame Rate: 50Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
• Image Functions: BLC (Backlight Compensation), HLC (Highlight Compensation), 3D DNR (3D Digital Noise Reduction)
• Wide Dynamic Range: WDR 120dB
• Image Settings: Saturation, Exposure, Contrast, Sharpness, AGC (Automatic Gain Control), White Balance
• Day/Night Mode: Auto / Manual Switching

Network

• Network Interface: 1x RJ45 Ethernet 10/100 Mbps self-adaptive
• Network Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
• Compatibility: ONVIF, ISAPI
• Simultaneous Live View: Up to 6 channels
• Alarm Trigger: Motion Detection, Video Tampering, Illegal Login
• Number of Users / Hosts: Up to 32 users, 3 permission levels: Administrator, Operator, User
• Client Software: iVMS-4200, Hik-Connect, HiLookVision

General

• Power Supply: 12V DC or PoE (802.3af, Class 3)
• Material: Metal + Plastic
• Ingress Protection: IP67
• Dimensions: 184.1 × 66 × 69.1 mm (7.25 x 2.6 x 2.7 inches)
• Weight: 0.43kg (0.95 lbs)
