Lauko IP kamera Hikvision DS-2CD1021-I, 2.8 mm

Trumpai apie prekę

Prekė: Lauko IP kamera Hikvision DS-2CD1021-I, 2.8 mm. Kategorija: IP kameros.

• Gamintojas: Hikvision
• Modelis: DS-2CD1021-I/2.8MM/E

IP camera Hikvision DS-2CD1021-I(2.8mm)(E)

IP camera Hikvision DS-2CD1021-I is a professional monitoring device with high quality vision. It is a tube model, designed for monitoring installations of all sizes. It is recommended both in industrial spaces, as well as in home systems or a small company. The relatively low price and small size of the housing with excellent image quality, as in industrial series, is an undoubted plus of this camera model.

IP cameras are used in changing observation conditions, which is why they are equipped with a number of technologies ensuring insensitivity and active adaptation to a heterogeneous monitoring environment.

The Hikvision DS-2CD1021-I IP camera has a 1/2.8 CMOS sensor with progressive scanning that captures images at 2 MP (1920×1080) resolution. This ensures a high-quality image, with visible details and natural color reproduction. It has a fixed focal length lens of 2.8 mm and a viewing angle of 105.8°.

The camera housing has IP 67 protection class, which provides effective protection against weather conditions (full resistance to dust and water) and acts of vandalism.

The camera can be powered conventionally (from a 12V power supply) or via PoE technology that allows you to transfer data and power with one cable using the appropriate recorder or switch. The device has a built-in SMART IR infrared heater, which allows you to get good image quality in difficult conditions, e.g. at night or without any lighting.

WDR or DNR functions improve the image recorded in the daytime scenery, while functions such as ANR or Hot Spare allow you to protect yourself against loss of recordings.

The most important functions of the camera

• Thanks to this, we reduce the time of viewing video materials as much as possible and we have the option of receiving notifications if motion appears in the camera’s field of view.

D-WDR

• (Wide Dynamic Range) wide range of exposure dynamics, i.e. equalization of strong contrasts and brightness differences. Improves the reproduction of the scene in case of large differences in the lighting level of its various fragments.

3D DNR

• (Digital Noise Reduction) function of digital noise reduction in the image. It filters the pixels of the transducer to remove noise-related effects in the recording resulting from interference (resulting, for example, from changes in signal intensity) and correct color rendering by the camera. Thanks to this solution, it is possible to save clean and transparent recordings both during the day and at night.

AGC

• (Automatic Gain Control) advanced function, allowing you to systematically increase the signal level. The correction applied on an ongoing basis ensures stable image quality captured under changing observation conditions.

AES

• (Automatic Electronic Shutter) function of electronic automatic shutter, which guarantees proper exposure of the material regardless of changes in lighting.

BC

Camera type

Fixed position

Resolution

Full HD 1080p

Matrix

1/2.8" progressive scan CMOS

Lens

2,8 mm @F2.0, horizontal field of view 105,8°, 4 mm @F2.2, horizontal field of view 83,6°

6 mm @F2.0, horizontal field of view 55°

Horizontal Viewing Angle

105 °

Built-in speakers

No

Two-way transmission

Yes

Night mode

Yes

Motion detection

Yes

Minimum sensitivity

0.1 lx

Minimum lighting

0 lx

Network protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour

Special Features

Settings - Brightness, saturation, contrast, sharpness can be adjusted using a web browser or client software

Leak-proof class

IP67

Power supply

• Power supply 12 VDC 25%, PoE (802.3af)
• Power consumption max. 5 W/6,5 W (POE)

Colour

White

Dimensions

69.1 mm × 66 mm × 172.7 mm ( 2.7" × 2.6" × 6.8")

Weight

500 g

Other parameters

• Shutter speed -1/3 s to 1/100, 000 s
• Free snapshot
• Day & Night - IR filter with automatic switch
• Image Features - 3D DNR, DWDR
• Adjustment range - Horizontal: 0° to 360°, Inclination: -90° to 90° Rotation: 0° to 360°
• Focal length/angle - 2.8 mm @F2.0
• Lens mount -M12
• IR range - Up to 30 m
• Compression - H.264+/H.264/MJPEG
• Operating temperature -30 °C is 60 °C, humidity 95% or less (non-condensing)

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Product weight with unit packaging	1.6 kg
Parametry	EAN (GTIN)	6941264026341
Parametry	Manufacturer code	DS-2CD1021-I/2.8MM/E
Parametry	Brand	Hikvision
Parametry	Model	DS-2CD1021-I/2.8MM/E
Parametry	Kind	external
Parametry	Batteries included	no
