Komutatorius Planet XGS-6350-24X4C, pagal užsakymą

Trumpai apie prekę

Prekė: Komutatorius Planet XGS-6350-24X4C, pagal užsakymą. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: Planet
• Modelis: XGS-6350-24X4C

Planet XGS-6350-24X4C on request

Planet

Powerful solution with 100 Gbps bandwidth for all long-range networks

PLANET XGS-6350-24X4C is a high-performance managed Layer 3 switch that meets the requirements of next-generation networks in the metropolitan area, data center, campus and enterprise. It has a density of 24 optical 10G SFP+ ports and 4 optical 40G/100GbE QSFP28 ports supplied in a robust 1RU housing.

The XGS-6350-24X4C is equipped with a complete Layer 3 management feature with support for a wide range of protocols and applications, making it easy to quickly deploy and manage services across both traditional Layer 2 and Layer 3 networks. With support for advanced features such as RIP, OSPF, BGP, PIM-DM/SM, etc., this switch is ideal for traditional or fully virtualized data centers.

The administrator can flexibly select the appropriate transceivers depending on the transmission distance or the required transmission speed, which allows for efficient expansion of the 1G/10G/40G/100G network. In addition, with a bandwidth of 800 Gbps, the XGS-6350-24X4C can handle massive amounts of data in a secure topology connecting to the main core of the network or high-bandwidth servers where audio, streaming and multicast applications are used.

Extraction power supply design for increased flexibility

The XGS-6350-24X4C is equipped with an AC power supply unit with a voltage of 100~240V, which makes it easy to replace for users. In addition, the XGS-6350-24X4C has another emergency power socket on the rear panel, so users can add a second AC or DC power source to the emergency power supply installation. The choice between AC and DC power is optional. The emergency power system is specifically designed to meet the demands of high-tech facilities that require the highest power integrity.

High efficiency

The XGS-6350-24X4C features a powerful switch architecture that is capable of delivering non-blocking switch capacity and bandwidth of 800 Gbps, greatly simplifying LAN upgrade tasks to meet growing bandwidth requirements.

Rich multi-level protocols

The XGS-6350-24X4C is equipped with comprehensive Level 3 management features with support for various protocols and applications, making it easy to quickly deploy and manage services on both traditional L2 and L3 networks. With support for advanced features such as RIP, RIPng, OSPFv2, OSPFv3, BGP, BGP4+, etc., this switch is ideal for traditional or fully virtualized data centers.

Strong multicast

The XGS-6350-24X4C supports numerous multicast functions. In Layer 2, it includes IPv4 IGMPv1/v2/v3 snooping and IPv6 MLD v1/v2 snooping. With Multicast VLAN (MVR) registration, you can control multicast senders and recipients and detect illegal multicast sources. Layer 3 multicast protocols include PIM-DM, PIM-SM and PIM-SSM, making the XGS-6350-24X4C an ideal solution for building high-performance networks.

Full IPv6 support

The XGS-6350-24X4C supports IPv4 to IPv6 technologies, including manual/automatic IPv4 tunneling, IPv6 to IPv4 tunneling, and ISATAP (Intra-Site Automatic Tunnel Addressing Protocol). It fully supports IPv6 Neighbor Discovery, DHCPv6, Path MTU Discovery, Telnet, SSH and IPv6-based ACLs, meeting the needs of device management and IPv6 network service control.

High reliability

Key components of the XGS-6350-24X4C, such as the management module, power supply system and ventilation system, support dual redundancy design. All system modules support hot swap and seamless change without the need for manual intervention.

It supports software updates in progress (ISSU) and Graceful Restart (GR) for the OSPF/BGP routing protocol, ensuring uninterrupted transfer of user data during system updates. It also supports a mechanism for detecting failures and restoring a service in seconds using the BFD (Bidirectional Forwarding Detection) protocol, connecting it to the Layer 2 or Layer 3 protocol.

Excellent and safe motion control

The XGS-6350-24X4C is equipped with powerful traffic management and WRR features that enhance the quality of services offered by telecommunications companies and enterprises. WRR features include Layer 4 level traffic qualifiers running at a forwarding rate and bandwidth limitation, which is especially useful for multi-customer, multi-branch, Telco or network services applications.

Powerful Layer 2 to Layer 4 security

Supported ACLs allow you to classify traffic based on source/target IP addresses, source/target MAC addresses, IP protocols, TCP/UDP ports, IP priority, time ranges, and ToS. In addition, different traffic forwarding policies can be applied. The XGS-6350-24X4C also provides port-level access authorization according to IEEE 802.1x, which can be deployed using RADIUS to ensure port-level security and block illegal users. With these features, the XGS-6350-24X4C enables enterprises and campuses to take full advantage of limited network resources and guarantees the best performance in VoIP and video conferencing.

Layer 2 Features

The XGS-6350-24X4C can be programmed for basic switch management functions such as port speed configuration, port aggregation, VLAN, Spanning Tree protocol, WRR, bandwidth control and IGMP snooping. It also supports 802.1Q labeled VLAN, Q-in-Q, voice VLAN and GVRP protocol. In addition, the number of VLAN interfaces is 1K, and the number of VLAN IDs is 4K. With support for port aggregation, the XGS-6350-24X4C allows for a high-speed connector that connects multiple ports. Allows up to 32 groups to join a connector with up to 8 ports in each group.

Efficient and safe management

For efficient management, the XGS-6350-24X4C Managed 100Gigabit Switch is equipped with console management interfaces, website management interfaces and SNMP. With its built-in website management interface, the XGS-6350-24X4C offers an easy-to-use, platform-independent management and configuration interface. The XGS-6350-24X4C supports the Simple Network Management Protocol (SNMP) and can be managed using SNMP-compliant management software. To reduce product learning time, the XGS-6350-24X4C offers Cisco-compatible commands via Telnet or the console port. In addition, the XGS-6350-24X4C enables secure remote management by supporting SSH connections that encrypt package contents in each session.

Centralized management of stack equipment

Several XGS-6350-24X4C switches can be used to build a virtual logical object. The XGS-6350-24X4C enables enterprises, service providers and telecommunications companies to have flexible control over port density, uplinks and switch stack performance. The XGS-6350-24X4C can act as a ring to achieve redundancy and ensure data integrity even in the event of a single switch failure in the stack. You can even hot-swap switches without disrupting your network, which greatly simplifies LAN upgrade tasks to meet growing bandwidth requirements.

Solution with flexible extension possibilities

The XGS-6350-24X4C provides twenty-four 10 Gbps SFP+ interfaces and four 100 Gbps QSFP28 fiber interfaces. Each of the SFP+ slots supports two speeds, 10GBASE-SR/LR or 1000BASE-SX/LX, and each of the QSFP28 slots supports native 100 Gigabit, 40G and 4 x 10 Gigabit Ethernet. Therefore, the administrator can flexibly select the appropriate SFP transceiver, taking into account not only the transmission distance, but also the required transmission speed. The length can be increased from 550 meters to 2 km (multimode fiber) or even up to 10/20/30/40/50/70/120 km (single-mode fiber or WDM fiber). They are perfectly suited for applications in enterprise data centers and distribution.

Redundant Ring, Quick Restore for Critical Web Applications

The XGS-6350-24X4C supports redundant ring technology and features strong and fast self-restore capabilities to prevent interruptions and external threats. It introduces advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching) technology and spanning tree protocol (802.1s MSTP) into the customer’s network to improve system reliability and uptime in harsh environmental conditions. In a simpler ring network, the restore time can be less than 50 ms, allowing you to quickly restore normal network operation.

• Redundant Power Supply: Yes
• Management: Yes
• Main Port Type: SFP / SFP+
• Main Port Throughput: 10G
• PoE Support: No
• Device Type: Media Converter
• Quantity in Collective Packaging: 2 pcs
• Height: 4.46 cm
• Width: 44.25 cm
• Depth: 30.01 cm
• Weight: 5.716 kg
• Manufacturer Details: PLANET TaiwanNew Taipei City2314110F No. 96 Minquan Rd. Xindian Dist. New Taipei City Taiwan sales@planet.com.twwww.planet.com.tw +886222199518
• EU Responsible Person Details: Konsorcjum FEN Sp. z o.o.PolskaPoznań60-415Czarnkowska 13Konsorcjum Fen sp. z o. o.gpsr@fen.plhttps://b2b.fen.pl/+48 616690700

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer	Planet
Parametry	Number of ports	24
Parametry	LAN port operating standard	10/100/1000 Mbps
Parametry	EAN (GTIN)	4711605283915
Parametry	Manufacturer code	XGS-6350-24X4C
