Komutatorius IP-COM F1110P-8-102W, juodas

Trumpai apie prekę

Prekė: Komutatorius IP-COM F1110P-8-102W, juodas. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: Ip-Com
• Modelis: F1110P-8-102W

• 8x RJ45 10/100 Mbps PoE ports with auto-negotiation (PoE IEEE 802.3af/at)
• 2x 10/100/1000 MB/s gigabit ports
• Maximum output power of each PoE port: 30,8 W
• Maximum switch output power: 99 W
• Each port supports 51V DC power supply for PoE powered device
• Metal desktop enclosure
• 102W Output Power Supply
• Transmission over long distances
• Lightning protection 6 KV
• Support full and half duplex 10/100M
• MAC process support Learning and Aging address
• Plug-and-Play operation, without configuration

IP-COM F1110P-8-102W switch is a 10-port switch (including 8 PoE ports) for desktop computers.

It is equipped with 8x Fast Ethernet 10/100 BASE-TX ports and 2x Gigabit Ethernet 10/100/1000 BASE-T ports .

Ports 1-8 support IEEE 802.3at PoE with each port providing 15.4W or support IEEE 802.3af PoE+ with each port providing 30W .

The entire device can provide power up to 99W .

In addition, all ports support 6kV lightning protection and long-distance data transmission and power supply up to 250m , which reduces the difficulty of implementation and therefore reduces costs.

6kV lightning protection

Ports and built-in power supply can provide lightning protection up to 6kV. It also provides protection against PSE short circuit, PoE overload, overheating, surges and surges.

PoE+ and Dual Gigabit Uplink

Ports 1-8 support IEEE 802.3at and IEEE 802.3af PoE. It provides up to 30W of PoE power per port and up to 99W per device. Two gigabit uplink ports allow you to cascade more devices.

250 meters of transmission

With 8-pin and professional network extension technology, the power and data transmission distance can be up to 250 meters, which can work instead of network extender or fiber optic to expand the network at no extra cost.

The F1118P-16-150W switch supports 3 operating modes:

• default mode: the device acts as a general switch, and all ports support 10/100 Mbps auto-negotiation
• VLAN mode: 1-8 ports can be isolated from each other, but 1-8 ports can connect to 9/10 port when VLAN is opened to stop broadcast storm to increase frame rate
• Extended mode: if expansion mode is enabled, VLAN isolation is enabled. Port 1-4 will be properly isolated (automatic 10 Mbps negotiation), but can communicate with Uplink port. And the power and network data delivery distance is up to 250m (10Mbps)

• Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
• MTBF: ≥50,000 hours (about 5 years)
• Indicators: Link/Act, PoE Status, Power, 1000M
• Fixed Ports: 8x 10/100Base-TX RJ45 Ports (Date/Power), 2x 10/100/1000Base-T RJ45 Port (Date)
• lightning protection: 6KV
• Wire-speed forwarding: Support
• Switching capacity: 5.6 Gbit/s
• Mac Address Table: 4K MAC
• PoE Supply: Port 1 to Port 8 support standard IEEE802.3at/af power (maximum power for each port is 30W), PoE power type is end-span (1245+, 3678-line pair), in full configuration: PoE Max Power Supply: 99W
• Dimensions: 177.5 x 104 x 26 mm (W × D × H)
• Input Voltage: AC: 100－240V～ 50/60Hz, DC: 51V /2.1A (Power Adapter）
• Environment: Operating Temperature: 0℃~40℃ (32℉~104℉), Storage Temperature: -40℃~70℃ (-40℉~158℉), Operating Humidity: 10%~90% non-condensing, Storage Humidity: 5%~90% non-condensing
• One-key Mode
• Default Mode: If Default mode is enabled, the device works as a general switch and all ports support 10/100Mbps auto-negotiation.
• VLAN Mode: 1-8 port can be isolated each other but 1-8 port can connect to 9/10 port after open VLAN to stop broadcast storm to increase forwarding rate of frame.
• Extend Mode: If Extend mode is enabled, VLAN isolation is enabled. Port 1-4 will be isolated respectively (10Mbps auto-negotiation), but can communicate with the Uplink port. And the delivery distance of powering and network data is up to 250m (10Mbps).
• Certification: CCC, FCC, CE, RHOS

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer	Ip-Com
Parametry	Product weight with unit packaging	1.6 kg
Parametry	Number of ports	10
Parametry	LAN port operating standard	10/100 Mbps
Parametry	EAN (GTIN)	6932392831372
Parametry	Manufacturer code	F1110P-8-102W
Parametry	Certificates of conformity	CE
