IP vaizdo kamera TP-Link VIGI S445ZI, 4MP, 5x priartinimas, naktinis matymas 60 m, WDR, IP67, IK10, garsiakalbis

Trumpai apie prekę

Prekė: IP vaizdo kamera TP-Link VIGI S445ZI, 4MP, 5x priartinimas, naktinis matymas 60 m, WDR, IP67, IK10, garsiakalbis. Kategorija: IP kameros.

• Gamintojas: Tp-Link
• Modelis: InSight S445ZI VIGI 4MP

• Manufacturer: TP-LINK
• Manufacturer code: InSight S445ZI
• EAN: 8885020623550

The most important features of the product

• 4MP Super HD resolution
• Motorized lens 2,7 – 13,5 mm – 5x optical zoom
• IR infrared range up to 60 m
• Classification of people and vehicles
• Smart detection (intrusion, line, object leaving, etc. )
• True WDR 120 dB, Smart IR, 3D DNR
• Two-way audio transmission
• Emergency Input and Output
• H.265+ encoding
• IP67 and IK10 resistance
• Supports microSD cards up to 512 GB
• Integration with VIGI VMS, VIGI Cloud, VIGI application

Professional zoom camera for 24/7 surveillance

TP‑Link VIGI InSight S445ZI is an advanced 4MP network camera designed for demanding monitoring installations in companies, industrial facilities, warehouses, stores and perimeter protection systems. Equipped with a motorized 2,7 to 13,5 mm (5x optical zoom) lens, it allows you to precisely adjust the field of view to the scene, increasing the effectiveness of surveillance and minimizing false alarms.

With an IR range of up to 60 m, the camera provides clear images even in complete darkness. Advanced image technologies such as True WDR 120 dB, Smart IR, 3D DNR and intelligent exposure correction guarantee a natural and clear image in all lighting conditions.

The S445ZI supports classification of people and vehicles, numerous Smart Detection functions and alarm integration (input/output), making it an ideal component of professional safety systems.

The camera has a resistance class of IP67 and IK10, thanks to which it is adapted to work in difficult weather conditions and exposed to acts of vandalism.

Technical data

Camera

• 1/2.9” Progressive Scan CMOS sensor
• Sensitivity: 0,005 Lux / 0 Lux with IR
• Shutter: 1/3 – 1/10000 s
• Night mode: IR filter, Auto/Schedule/Unified

Lens

• Type: motorized, zoom
• Focal length: 2,7 – 13,5 mm (5x optical zoom)
• Aperture: F1.6
• Field of view: Horizontal: 29,6°–102° Vertical: 16,8°–53,8° Diagonal: 34,1°–122,8°
• DORI: Detection: 66 to 207 m Observation: 28 to 86 m Recognition: 13 to 41 m Identification: 7 to 21 m

IR illumination

• 4 IR LEDs
• Range: 60 m
• Wavelength: 850 nm
• Modes: Auto / Schedule / On / Off

Video

• Max. resolution: 2688 × 1520
• Main stream: up to 25/30 fps
• Side stream: up to 25/30 fps
• Compression: H.265+ / H.265 / H.264+ / H.264
• Bitrate: Main: 256 Kbps – 6 Mb/s Side: 64 Kbps – 1024 Kbps
• WDR: 120 dB
• Image Correction: BLC/3D DNR/HLC/Smart IR
• Privacy mask: up to 4 zones
• ROI: 1 region

Audio

• Built-in microphone (range approx. 4,5 m)
• Audio input
• Audio Output
• Compression: G.711 alaw
• Bitrate: 64 Kbps

Network

• Port: 1 × RJ45 10/100 Mbps (PoE)
• PoE: 802.3af/at
• Protocols: TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, NTP, SMTP, SNMP, IPv4/IPv6, etc.
• ONVIF: Profile S/T/G
• Client: VIGI App, Web, VIGI VMS, Cloud VMS, PC Client
• Browsers: Chrome 57+, Firefox 52+, Safari 11+, Edge 91+
• Security: HTTPS, IP filter, password protection

Alarms and Events

• Smart Detection: intrusion, line, entry/exit from zone leaving/theft object vagabond detection people vehicle detection unexpected sound scene change
• Basic: traffic, sabotage, wrong login
• Reactions: recording, push, email, FTP, alarm output

Ports and memory

• 1 × alarm input
• 1 × alarm output
• microSD slot up to 512 GB (not included)
• Reset

Power supply

• 12V DC ±5% (max 10,8 W)
• PoE 802.3af/at (max 12 W)

Resilience and working conditions

• IP67
• IK10
• Operating temperature: -30°C to 60°C
• Humidity: ≤95% (non-condensing)

Dimensions and material

• Dimensions: Φ112,3 × 92,5 mm
• Material: metal
• Net weight: 0,71 kg
• Gross weight: 0,96 kg

Contents of the pack

• Camera VIGI InSight S445ZI
• Instructions
• Cable seals
• Mounting accessories

Certificates

• CE, FCC, KC, BSMI, VCCI, IP67, IK10, ONVIF
