IP vaizdo kamera PX-DI4028IR2DLPW, 4 Mpx

Trumpai apie prekę

Prekė: IP vaizdo kamera PX-DI4028IR2DLPW, 4 Mpx. Kategorija: IP kameros.

• Gamintojas: IPOX
• Modelis: 1858

Description

PX-DI4028IR2DLPW is an economical turret camera with a plastic body of the IPOX brand working in the technology of double illuminator so-called. Dual Light. In practice, the use of two types of LEDs in the camera - IR with infrared light and LED with warm white light allows you to get a traditional black and white image or color image at night. The device uses a CMOS sensor in the image capture process, which allows you to capture recordings in 2560×1440 (4Mpx) resolution. The fixed focal length lens used in the device allows for quick adaptation of the camera without the need for additional interference from the user. The camera is equipped with basic AI functions that allow you to identify a person after crossing a line or violating a zone.

• Functional menu

Using the intuitive menu of the program, it is possible not only to test the cameras and the current preview of the recorded image, but it is also possible to set advanced parameters and functions of the device.

• Smart Dual Light - decide how to illuminate at night

The presented IPOX Light Explorer camera is equipped with Smart Dual Light technology, thanks to which it is possible to switch between different lighting modes in the camera. The use of a dual IR + LED illuminator with SMART technology allows you to turn on white light only if a human camera is detected in the viewing zone. In the event that a person leaves the monitored area, the white light LED illuminator is automatically switched to IR lighting.

• Color image 24/7

The IPOX Light Explorer camera guarantees vivid images around the clock even in very low light conditions. This feature has a positive effect on safety and allows for accurate identification of people and property. The ability to capture detailed images in low light comes from a combination of a white light illuminator, and a photosensitive transducer. The use of these functions allows more light to enter the camera, making it possible to capture images in a full color palette with high brightness.

• AI functions in IPOX cameras

The deep learning algorithm is aimed at effective recognition of people. This provides fewer false positives, greater flexibility and positively affects the accuracy of monitoring, which directly contributes to increasing the level of safety in the observed area.

• Perimeter protection

The camera is equipped with line crossing and intrusion detection functions. AI technology allows you to identify an object on the recording as a person and only after verification trigger the alarm. At the same time, the system will omit emergency situations for which they are responsible, e.g. passing vehicles, leaves moving in the wind, running animals, rain or turning on lighting.

• Detection of left and missing objects
• Digital noise reduction - DNR
• Wide dynamic range - DWDR
• Area of increased interest - RoI
• Massaging of light sources - HLC
• Privacy masks
• Motion detection system
• Notifications from alarm events
• Camera with PoE technology
• Secure data transfer with encrypted HTTPS connection
• Compression H.265

• Fixed-focal object

The IPOX PX-DI4028IR2DLPW is equipped with a fixed focal length 2.8 mm lens with an aperture of F2.2 and a viewing angle of 112° (diagonal).

• IP67 enclosure

The body and camera holder are made of plastic, while the spherical part is divided into: the lower one made of plastic and the upper metal. The camera shows IP67 tightness.

• Extended technical support, free software

• NVMS

NVMS (Network Video Monitoring System) is a client program that enables seamless cooperation with IPOX devices and supports the management of third-party products through the ONVIF m.in protocol. Dahua and Hikvision.

• Fast startup of IP system

The available software allows you to quickly configure IP cameras to work in a given monitoring system. The appropriate software is the IP Tool application and the PRO Manager program. The first one allows you to easily search and add equipment and download and edit information about devices on an ongoing basis, while the second one is responsible for comprehensive, more professional management of surveillance cameras. The IPOX IP TOOL program is recommended for small monitoring structures, while the IPOX PRO MANAGER is dedicated to both small and large monitoring systems based on PRO series cameras. Current versions of the programs can be downloaded directly from our website.

Specification

MAIN

Converter:1/3" 4MP Progressive Scan CMOS

Resolution:4Mpx, 2560 × 1440 pixels

Tenderness:

• 0.09 lux @ F2.2 (AGC ON)
• 0 lux @ IR LED ON

Lens:2.8 mm @ F2.2

Angle of view:Horizontal: 96°; vertical: 53,7°; diagonal: 112°

Snapshot:1/3 ~ 1/100 000 s (automatic / manual)

Adjustment range:Panorama (pan): 0° ~ 360°; slope (tilt): 0° ~ 75°; rotation: 0° ~ 360°

DORI

• Detection (25 px/m): 57 m
• Observation (63 px/m): 23 m
• Recognition (125 px/m): 11 m
• Identification (250 px/m): 6 m

ILLUMINATOR

LED type:

• IR (Infrared)
• LED (white light)

Number of diodes:

• 1x IR LED
• 1x LED

Range: 10 ~ 20 m

Smart IR: Yes

Automatic over-exposure control function: Yes

White light intensity adjustment: 1 ~ 100

Illuminator setting*

3 modes of operation of the illuminator (IR only, LED only, Smart - IR + LED)

1. LED (visible, white light) - during the day the illuminator remains off; turns on automatically after dark; this mode provides a color image at night

2. IR (invisible, infrared light) - after dark, the camera illuminates the infrared image; color image during the day, black and white at night

3. Smart IR + LED (default) - mode combining both types of illuminators; the camera illuminates the infrared image after dark and only when a person is detected in the image turns on the white light and switches to color mode

*To change the illuminator mode, go to Settings -> Stream -> Display -> Lighting type in the settings and select the appropriate option there


System: PAL (50 Hz) / NTSC (60 Hz)

Video Compression:Main Stream: H.265+ / H.265 / H.264+ / H.264

Sub Stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

Processing Resolution:2560×1440 (4Mpx) / 2304×1296 (3Mpx) / 1920×1080 (2Mpx) / 1280×720 (1Mpx) / 704×576 (D1) / 640×480 (VGA) / 480×240 / 352×288 (CIF)

Processing Speed and Resolution

(Main Stream):

• 50 Hz: 1 ~ 25 fps @ 4Mpx / 3Mpx / 1080p / 720p
• 60 Hz: 1 ~ 30 fps @ 4Mpx / 3Mpx / 1080p / 720p

Processing Speed and Resolution

(Sub Stream):

• 50 Hz: 1 ~ 25 fps @ D1 / VGA / 480×240 / CIF
• 60 Hz: 1 ~ 30 fps @ D1 / VGA / 480×240 / CIF

Bitrate:64 Kbps ~ 3 Mbps

Image Downloading:From Sub Stream

Settings:AWB (Manual 0 ~ 100), AGC (Manual 0 ~ 100), BLC, HLC, MIR, FLIP, DNR, DWDR, ROI

Adjustment:Saturation, Brightness, Contrast, Hue, Sharpness, Noise Reduction

Flicker Filter:60 Hz / 50 Hz

Day/Night Mode:3 profiles (Auto, Manual, Schedule), 3 sensitivity levels, transition delay 2 ~ 120 s

Video Settings Configuration:3 profiles (Day, Night, Universal) with work schedule option

AUDIO (DISABLED BY DEFAULT)

Compression: G.711A, G.711U

Built-in microphone: Yes

Microphone volume level: 0 ~ 100 (default 75)

CONNECTORS

Ethernet: 1x RJ-45 10Base-T/100Base-TX

Power supply: 1x socket 5,5/2,1 on the cable

FUNCTIONS

Protocol support: Onvif Profile S (22.12)

Integration: API

Supported protocols: HTTP, HTTPS, NTP, RTSP, IPv4, IPv6, DHCP, PPPoE, 802.1X, WebSocket

Menu languages: English, Spanish, Polish, Portuguese, Russian, Italian

OSD: Date, camera name, watermark

Online users: Max. 3 connections

Login lock: Yes, after 6 failed attempts

Ability to disconnect the connection: Yes, from the administrator

Password security: 3 difficulty levels and the ability to set the time after which you need to change the password to a new one (from 30 days to never)

Address filtering: IP, MAC

Notifications: IP address change, incorrect login, motion detection, sabotage, line crossing, intrusion detection (zone violations)

Video event alarm sustain time: 1 s / 3 s / 5 s / 10 s / 20 s / 30 s / 60 s / 2 min

Motion detection: Any number of zones, adjustable sensitivity 1~8, action schedule

Motion detection fields: 396 (22×18)

Privacy zones: 4 zones

ROI: 3 areas (level 1 ~ 10)

Prevention: Automatic / manual restart

MANAGEMENT

Browsers: (Windows / MacOS / Linux) Edge, Safari, Opera, Chrome, Firefox, etc. - plug-in interface (main stream preview max. 1080p), Internet Explorer - requires plugin installation

CMS (Windows/macOS): NVMS 2.0

Mobile devices (Android / iOS): IPOX PRO

Basic:Protection of objects (detection of left/taken objects; 1 area), motion detection, exception (network disconnection, IP address conflict, illegal login), sabotage (change detection: scenes, blurring)

Motion detection:Motion detection based on object recognition (humans only)

Perimeter protection (perimeter):Line crossing detection (4 lines), intrusion detection (4 zones) - all based on object recognition (humans only)

Filtering false alarms

*Attention! The filter function is available simultaneously for only one analysis function (enabling one will disable the other)

OTHER

Compliant with NDAA: Yes

Protection class: IP67

Construction

Spherical part: metal / plastic

Handle: plastic

Ring: plastic

Power supply: 12 V DC or PoE 802.3af

Power consumption: < 5 W with illuminator on< /p>

Moisture : < 95% (non-condensing)< /p>

Working temperature: -20°C ~ +55°C

Weight: approx. 280 g

Dimensions (dia. /H ): ø94,8×82,8 mm

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	EAN (GTIN)	5904194158019
Parametry	Manufacturer code	1858
Parametry	Brand	IPOX
Parametry	Model	1858
Parametry	Packaging status	original
Parametry	Batteries included	no
