IP vaizdo kamera Hikvision DS-2CD2086G2H-IU, juoda, 2.8 mm, AcuSense, su mikrofonu

Trumpai apie prekę

Prekė: IP vaizdo kamera Hikvision DS-2CD2086G2H-IU, juoda, 2.8 mm, AcuSense, su mikrofonu. Kategorija: IP kameros.

• Gamintojas: Hikvision
• Modelis: DS-2CD2086G2H-IU

IP camera 8MPx, AcuSense, DarkFighter, IP67, IR40m, microphone

DS-2CD2086G2H-IU tube camera operates on the basis of AcuSense technology, which using Deep Learning algorithms enables the classification of objects (vehicle / human), and thus the filtration of false alarms from VCA events, e.g. Perimeter protection. The camera is equipped with a modern 1/1.8" Progressive Scan CMOS image sensor, which allows you to record video recordings at a maximum speed of 25/24 fps at a resolution of 3840×2160 (8Mpx). The camera is equipped with a fixed focal length lens with an aperture of F1.0 and an intelligent SMART infrared heater.

• Transducer: 1/1.8" Progressive Scan CMOS
• Resolution: 3840x2160 (8Mpx) @ 25/30kl/s
• Lens focal length: 2.8mm
• IR radiator: 2x Smart IR LEDs (40m)
• Day/night automatic mode: Yes
• Compression: H.265+/ H.265/ H.264+/ H.264/ MJPEG
• Features: AWB, AGC, BLC, HLC, 3D DNR, WDR 120dB, ROI
• AcuSense - object classification with alarm filtering
• Powered-by-DarkFighter - low light operation
• AI functions: perimeter protection, face detection, motion detection, object classification (human/vehicle)
• Interface: 1 RJ45 10 M/100 M
• Card support: microSD/SDHC/SDXC up to 512GB
• Built-in microphone
• Support: ONVIF, ISAPI, SDK
• Power supply: 12V DC or PoE 802.3af
• Housing: tightness class IP67
• Housing color: White
• Dimensions: 74 x 179,2 mm

ROI | WDR 120dB | 3D DNR | HLC | BLC

ROI (Region of Interest) allows you to deliver high-quality recording only from the area selected by the user. In others outside the ROI, the camera transmits an image of inferior quality or does not transmit it at all.

WDR 120 dB improves the reproduction of the scene in case of large differences in the lighting level of different parts of the scene. Typical applications for this functionality are glazed passages, entrances to buildings, etc. This technology flawlessly copes with recording images in the presence of large contrasts of light, which so often can interfere with the correct operation of the camera.

3D DNR It causes multidimensional filtering of transducer pixels to remove noise-related effects in the recording resulting from interference (resulting, for example, from changes in signal intensity) and correct color rendering by the camera.

HLC automatically detects spots in the frame that are too exposed and then lowers their brightness. This allows you to see all the details, e.g. License plates of cars, which works best at night or in the case of monitoring the underground car park.

BLC is a technology used in video surveillance systems that improves image quality in difficult lighting conditions, especially in situations where the background is heavily illuminated and the foreground becomes underexposed

IP camera supports Powered by Darkfighter technology, which makes it the best choice for very poor lighting conditions. DarkFighter is a technology that allows you to get high image quality in difficult lighting conditions, especially at night. Its main advantage is its ability to record details in places with low lighting levels, which makes it a valued technology in monitoring systems where ensuring safety is crucial.

AcuSense is primarily about detecting human and vehicle silhouettes, but also filtering alarms from sources other than people and vehicles. In addition, AcuSense series cameras, using the latest deep learning technology, are able to extract people and vehicles from a large video dataset and save snapshots of objects for efficient search.

Power over Ethernet (PoE) is a solution designed to carry out quick and uncomplicated installation of network devices and comfortable operation of equipment and easy modernization of installation. The PoE solution allows you to place the camera away from traditional power sources, which translates into saving the total number of wires necessary to start the device.

allows you to manage the camera without additional configuration on the router. With HIK-CONNECT, you have the ability to remotely control all camera functions at your fingertips.

HIK-CONNECT service is designed to work as well as with NVR and IPC cameras Hikvision. Thanks to the instant warning function, you can receive instant motion detection notifications so that we can take the necessary actions to ensure the safety of your property or loved ones.

Key Features:

1. Real-time live view.
2. Playback of recorded films.
3. Instant Alerts

• Converter: 1/1.8" Progressive Scan CMOS
• Sensitivity: Colour: 0.0008 Lux @ (F1.0, AGC ON) B/W: 0 Lux IR or LED ON
• Snapshot: 1/3 s to 1/100 000 s
• Position adjustment: Panorama (pan): 0° ~ 360°, slope (tilt): 0° ~ 90°, rotation: 0° ~ 360°
• Focal length: 2.8 mm
• Angle of view: Horizontal: 105,1°, vertical: 54,8°, diagonal: 128,2°
• Aperture: F1.0
• Attachment: M16
• Illuminator type: IR
• Number of LEDs: 2x IR LED
• Range: 40 m
• Intelligent illuminator: Yes
• IR wavelength: 850 nm
• Maximum resolution: 8.0 Mpx, 3840×2160 pixels
• Compression*: Main stream: H.265+ / H.265 / H.264+ / H.264 Auxiliary stream: H.265 / H.264 / MJPEG
• Type H.264: Baseline Profile / Main Profile / High Profile
• Type H.265: Main Profile
• Bitrate: 32 Kbps ~ 16 Mbps
• Bitrate control: CBR / VBR
• SVC: Yes, for H.265 and H.264
• ROI: Single-Region support for main and secondary streams
• Built-in microphone: Yes
• Ambient noise filtering: Yes
• Sampling: 8 kHz / 16 kHz / 32 kHz / 44,1 kHz / 48 kHz
• Compression: G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
• Bitrate: 64 Kbps (G.711ulaw / G.711alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 ~ 192 Kbps (MP2L2) / 8 ~ 320 Kbps (MP3)
• SNR: ≥52 dB
• Day/night mode: Day/night/auto/schedule
• Image enhancement features: BLC, HLC, 3D DNR
• WDR: 120 dB
• Privacy masks: 4x
• Image parameter switch: Yes
• Image functions: Rotate, saturate, brightness, contrast, sharpness, gain, white balance (adjustable via software or web browser)
• Live view: Up to 6 channels simultaneously
• Compliance with the standard: ONVIF (profile S, profile G, profile T), ISAPI, SDK, ISUP
• Supported network protocols: TCP/TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, WePoB, Web,
• Users: Support up to 32 users / 3 levels of access: administrator, operator, user
• Security: Password protection, Complex password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), Watermark, IP address filter, Basic and Digest authentication for HTTP/HTTPS, WSSE and Digest authentication for ONVIF, RTP/ RTSP over HTTPS, Audit timeout settings, Security audit log, TLS 1.1/1.2/1.3, Host authentication (MAC address)
• Archiving: MicroSD/SDHC/SDXC (512 GB), NAS (NFS, SMB/CIFS), ANR
• Remote support: iVMS-4200, Hik-Connect, Hik-Central
• Basic Ai functions: Motion detection, video tamper alarm, exception (network disconnection, IP address conflict, illegal login, full hard drive, hard drive error)
• Smart: Scene change detection
• Face Detection: Yes
• Motion detection: Yes (classification of people and vehicles)
• Perimeter protection: Line crossing detection, intrusion detection, region entry detection, region exit detection (all based on human and vehicle classifications)
• Filtering false alarms: Filtering analysis alarms based on object recognition (human, vehicle)
• Network: 1x RJ-45 10/100 Base-T/Base-TX
• Memory: 1x microSD/ microSDHC/ microSDXC card slot up to 512 GB
• Power supply: 1x socket 5,5/2,1 on the cable
• Reset: 1x button
• Languages: 33 languages
• Protection class: IP67 (IEC 60529-2013)
• Power Supply: 12 V DC (±25%) PoE (802.3af, Class 3)
• Power consumption: DC: max. 7 W (0,58 A, 12 V DC) PoE: max. 8,5 W (802.3af @ 36 V ~ 57 V)
• Moisture: < 95% (non-condensing)
• Working temperature: -30°C ~ +60°C
• Material: Metal
• Weight: 525 g
• Dimensions (Width /height /length ): 74,4×74,4×179,2 mm

• original product of the brand Hikvision
• instantly you will receive the purchased device
• full support during selection and commissioning
• If you have any doubts, we will be happy to advise and help

Specifications
