IP vaizdo kamera DAHUA 8 Mpx 4K, Dual Light, IPC-HFW2849S-S-IL-0280B, 2.8 mm

Trumpai apie prekę

Prekė: IP vaizdo kamera DAHUA 8 Mpx 4K, Dual Light, IPC-HFW2849S-S-IL-0280B, 2.8 mm. Kategorija: IP kameros.

• Gamintojas: Dahua
• Modelis: IPC-HFW2841S-S-0280B

IPC-HFW2849S-S-IL-0280B is an IPC dome camera of the WizSense series, used for the construction of vision systems. The WizSense device is equipped with innovative technologies: artificial intelligence AI (perimeter, SMD plus) and Smart Dual Illuminators. The Dahua camera is equipped with an image sensor 1/2.7" 8MP image sensor, low illuminance, HD CMOS , which allows you to generate an image in the maximum resolution of 3840x2160. Thanks to high sensitivity and available correction functions, including WDR 120Db, 3DNR, it provides an excellent image quality. The fixed-focal lens of the 2.8mm camera allows accurate recording of the observed scene. A new solution used in the Smart Dual camera is the ability to switch between different lighting modes (white light or IR infrared). In addition, artificial intelligence AI technology with perimeter protection increases the level of safety and guarantees the detection of all undesirable behaviors. The advantage of the device is also a built-in slot for microSD cards (256 GB) and a built-in microphone. The IPC megapixel camera is characterized by a high degree of resistance to adverse weather conditions (IP67).

DH IPC-HFW2849S-S-IL - DAHUA WizSense Smart Dual Illumination Series Camera

• sensor: 1/2,7" 8MP image sensor, low illuminance, HD CMOS
• resolution: 3840x2160 (8Mpx) @ 20fps
• Interface: 1x RJ45 Ethernet 10/100Mbps PoE 802.3af
• compression: H.265+/ H.265/ H.264+/ MJPEG
• Sensitivity: 0,008lux/F1,6, 0lux (IR/LED on )
• lens: 2,8mm
• Smart Dual illuminator:
• 1 IR LED (range 30m)
• 1 white light LED (range 30m)
• AWB, AGC, BLC, HLC, 3D NR, WDR 120dB, RoI
• Smart Dual Illuminators - the use of a dual illuminator
• 3 illuminator operating modes (IR only, LED only, Smart - IR + LED)
• Built-in microphone
• Supports microSD/microSDHC/microSDXC cards up to 256GB
• Support: ONVIF, CGI, Milestone, RTSP, RTMP, P2P
• AI functions: perimeter protection, object classification (human/vehicle)
• SMD+ - object classification with false alarm filtering
• Processing speed and resolution:
• 20 fps for 3840x2160 (8Mpx)
• 25/30 fps for 2688x1520 (4Mpx)
• bitrate: 32Kbps ~ 8192Kbps (H.264), 12Kbps ~ 8192Kbps (H.265)
• image preview:
• Smart PSS, DSS Express, DSS PRO
• Web browsers: IE, Firefox, Chrome
• mobile devices with systems: iOS, Android
• housing: tightness class (IP67)
• Power supply: 12V DC or PoE 48V (802.3af)

• MAIN
• 1/2,7" 8MP image sensor, low illuminance, HD CMOS
• 8Mpx resolution, 3840 (H) x 2160 (V) pixels
• RAM / ROM 256MB / 128MB
• Progressive Scanning System
• Automatic / manual shutter, 1/3s ~ 1/100000s
• Signal-to-noise ratio >56dB
• Minimum lighting 0,008 Lux/F1,6 (Color, 30 IRE) 0,0008 Lux/F1,6 (B/W, 30 IRE) 0 Lux (IR/LED on) )
• Illuminator 1 IR LED (Infrared) 1 White Light LED (Warm)
• IR illuminator range: 30m LED: 30m
• Illuminator Control Automatic / Manual
• Smart Dual Illuminators Smart Illumination: The camera operates on the basis of an IR illuminator. If an object is detected in a controlled zone, the illuminator switches to a white light LED. IR Mode: The camera only works with IR illuminator. White Light Mode: The camera only works with the white light LED illuminator.
• Panorama position adjustment: 0° ~ 360° Inclination: 0° ~ 90° Rotation: 0° ~ 360°
• LENS
• Type of Fixed Focal
• Mounting type M12
• Focal length 2,8mm (F1,6)
• Viewing angle H: 111° V: 58° D: 132°
• Aperture Type Fixed
• Macro mode (sharpness from) 1,5m
• Range DORI Detection: 84,8m Observation: 33,9m Recognition: 17,0m Identification: 8,5m
• PICTURE
• H.265 / H.264 / H.264B / H.264H MJPEG video compression (auxiliary stream)
• Smart Codec Yes (H.265+ / H.264+)
• Simultaneous number of video streams 2
• Processing resolution 8Mpx - 4K (3840x2160) / 6Mpx (3072x2048) / 3072x1728 / 5Mpx - 16:9 (2880x1620) / 4Mpx (2688x1520) / 3Mpx (2048x1536) / 2304x1296 / 1080 p - 2Mpx (1920x1080) / 960p - 1.3Mpx ( 1280x960) / 720p - 1Mpx (1280x720) / D1 (704x576 / 704x480) / CIF (352x288 / 352x240)
• Processing speed and resolution (main stream) PAL: 20fps @ 8Mpx / 25fps @ 4Mpx NTSC: 20fps @ 8Mpx / 30fps @ 4Mpx
• Processing speed and resolution (auxiliary stream) PAL: 25fps @ D1 / 25fps @ CIF NTSC: 30fps @ D1 / 30fps @ CIF
• Transmission rate control Variable (VBR) / constant (CBR)
• Bitrate 32Kbps ~ 8192Kbps (H.264) 12Kbps ~ 8192Kbps (H.265)
• Day / Night Automatic (ICR) / color / black and white
• BLC/HLC/WDR 120dB Background Compensation
• Gain Control Automatic (AGC) / Manual
• 3D NR Noise Reduction
• White Balance Automatic (AWB) / Natural / Street Lighting / Outdoor / Manual / Region
• Motion Detection On. / off. (4 areas, rectangles)
• Area of interest (Roi) Wł. / off. (4 areas)
• Smart lighting Yes
• Image rotation 0°, 90°, 180°, 270° (90° support, 270° for 2688x1520 and lower resolution)
• Mirror Reflection Support
• Privacy Zones On. / off. (4 areas)
• AUDIO
• Compression G.711a/G.711Mu/PCM/G.726
• Microphone Yes (built-in)
• ARTIFICIAL INTELLIGENCE (AI - DEEP LEARNING)
• Perimeter protection Line crossing, intruder detection (these two functions support classification and accurate detection of vehicles and people)
• SMD+ Classification (human/vehicle), false alarm filter
• Smart Search Collaborate with Smart NVR for accurate intelligent search, event extraction and merge into event videos
• ALARM
• Alarm event trigger Motion detection, sabotage, audio detection, missing/overflow/SD card error, connection loss, IP address conflict, unauthorized access, voltage anomaly, line crossing, intrusion, SMD
• INTERFACE
• Ethernet 1x RJ45 10/100Mbps Base-T
• DC 12V power supply 1x socket 5,5/2,1 on the cable
• Memory 1x microSD/ microSDHC/ microSDXC card slot up to 256GB
• NETWORK
• Supported protocols IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, Boujour
• Cyber security Video encryption, encryption configuration, WSSE, account lockout, IP/MAC filtering, security logs, cert generation and import. X.509, HTTPS, 802.1x, trusted execution, trusted update
• SDK and API Yes
• Support ONVIF (Profile S / Profile G / Profile T), CGI, Milestone, P2P
• Online users 20 users (total bandwidth 48M)
• NAS/FTP/SFTP Network Archiving/MicroSD Card
• Remote control CMS (Smart PSS), DSS, DMSS, P2P mobile devices: iOS, Android
• THE REMAINING
• LVD Certificates: EN62368-1 EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B 2023-02-22
• Housing material Camera front: metal Camera body: metal Handle: metal
• Protection class IP67
• DC 12V PoE DC 48V (802.3af)
• Basic Power Consumption: 2,7W (12V DC), 3,4W (PoE) Max. 5W (12V DC), 5,9W (PoE) - LED on + WDR + AI Features
• Humidity 0~95% (non-condensing)
• Operating temperature -40°C ~ +55°C
• Weight 470g
• Dimensions (D. /length ) ⌀70x166,2mm
