IP kamera Tianda TC-H332A, 3 Mpx, 4 mm, Wi-Fi, EU

Trumpai apie prekę

Prekė: IP kamera Tianda TC-H332A, 3 Mpx, 4 mm, Wi-Fi, EU. Kategorija: IP kameros.

• Gamintojas: no brand
• Modelis: TC-H332A SPEC:I2W/WIFI/EU/4MM

The Tiandy TC-H332A Wi-Fi Series IP camera is a modern device designed for monitoring living rooms and small commercial facilities. This model combines high image quality with a functional rotating design and Wi-Fi wireless connectivity, making the installation of a monitoring system quick and convenient. The camera can be used in homes, offices, shops or warehouses, providing constant supervision over the selected area.

The device is equipped with an image sensor 1/3" CMOS, which allows you to capture images at a maximum resolution of 3 megapixels (2304 × 1296 pixels). Thanks to this, the recordings are characterized by good detail, which makes it easier to identify people, objects or events in the monitored room. The camera also supports modern video compression standards S+265, H.265 and H.264, which allow you to reduce the size of video files and reduce network bandwidth consumption while maintaining high image quality.

Rotating design and wide range of observations

One of the most important features of the camera is its PT (Pan-Tilt) rotating design, allowing you to monitor a large space with a single device. The camera can rotate horizontally up to about 350°, while the vertical adjustment ranges from –90° to 90°. Thanks to this, it is possible to observe almost the entire room without having to install several cameras.

The TC-H332A features a 4 mm focal length lens with a F2.0 aperture, which provides a wide viewing angle of approximately 82° horizontally. This allows you to conveniently monitor a larger part of the room while maintaining good image detail. The camera also allows you to program up to 255 presets, i.e. saved rotation positions to which the device can automatically return during operation.

Clear picture day and night

The camera has been adapted to work in various lighting conditions. The minimum sensitivity of the transducer is about 0,02 lux in color mode, while in total darkness the device uses a built-in infrared illuminator. The range of the IR radiator is up to 15 meters, which allows effective monitoring even after dark.

In addition, the camera is equipped with a white LED with a range of about 8 meters, which can illuminate the scene at night, improving the visibility of details. The ICR automatic infrared filter is responsible for switching between day and night mode, providing natural colors during the day and a clear black and white image after dark.

Intelligent functions and audio communication

The TC-H332A also offers intelligent image analysis capabilities that enhance monitoring efficiency. The camera supports m.in. auto-tracking and a system of intelligent alarms responding to detected movement or other events in the frame. If an abnormality is detected, the device can start recording, take a photo or turn on a warning signal.

A big advantage of this model is also the ability to conduct two-way audio communication. The camera has a built-in microphone and speaker, thanks to which the user can not only hear sounds from the monitored room, but also communicate with people within its range. This feature is especially useful in homes, offices, or stores where you need to quickly connect with people at the camera.

Network connectivity and convenient remote access

The camera is equipped with a Wi-Fi module operating in the 2.4 GHz band (IEEE 802.11 b/g/n), which allows wireless connection to the local network. Thanks to this, the installation of the camera does not require additional network cables, which significantly facilitates its installation in any room. Wireless transmission range can reach about 30 meters, depending on ambient conditions.

Access to the camera image is possible both from the computer and mobile devices. The manufacturer provides dedicated Easy7 VMS software for computers and the EasyLive Plus mobile application, which allows you to view live images, view recordings or control the camera from anywhere.

Recording and independent operation of the system

The camera supports local recording on microSD, microSDHC and microSDXC memory cards with a maximum capacity of up to 512 GB. Thanks to this, it is possible to store recordings without the need for an external network recorder. This solution simplifies the installation of the monitoring system and reduces the costs of building the entire system.

The device is powered by 5 V DC voltage, and its maximum power consumption is about 7 W. The camera is designed to operate in temperatures from –10°C to +45°C, allowing it to be used seamlessly in most living and office spaces

• Standard: IP
• Converter: 1/3" Progressive Scan CMOS
• Maximum resolution: 3 Mpx (2304 × 1296)
• Working modes: 3 Mpx / 1080p / 720p
• Sensitivity: 0.02 lx (colour), 0 lx with IR illuminator on
• Snapshot time: 1/3 s – 1/100000 s
• Day/night mode: automatic (mechanical ICR filter)
• Video compression: S+265 / H.265 / H.264
• Main stream speed: up to 25 fps. /s at 3 Mpx
• Lens type: fixed focal length
• Focal lens: 4 mm
• Aperture: F2.0
• Angle of view: approx. 82°
• IR illuminator range: up to 15 m
• White LED light range: up to 8 m
• Horizontal rotation (PAN): 0° – 350°
• Vertical rotation (TILT): −90° – 90°

• Presets: to 255 items
• Optical Zoo: brak
• Digital Zoo: yes
• Motion detection: yes
• Auto-tracking: yes
• Audio: built-in microphone and speaker (two-way communication)
• Network interface: Ethernet 10/100 Mbps
• Wireless connectivity: IEEE 802.11 b/g/n Wi-Fi (2.4 GHz)
• ONVIF support: yes
• Memory card slot: microSD / microSDHC / microSDXC up to 512 GB
• Mobile access: EasyLive Plus app (Android/iOS)
• PC Software: Easy7 VMS
• Power supply: 5 V DC
• Power consumption: max. OK. 7 IN
• Housing: plastic
• Color: white
• Working temperature: −10 °C – +45 °C
• Working humidity: up to 95%
• Dimensions: approx. 120 × 75 mm
• Weight: approx. 0.2 kg
