IP kamera Hikvision DS-2CD2A46G2T/P-IZSY/ANPR, 4 Mpx

Trumpai apie prekę

Prekė: IP kamera Hikvision DS-2CD2A46G2T/P-IZSY/ANPR, 4 Mpx. Kategorija: IP kameros.

• Gamintojas: Hikvision
• Modelis: DS-2CD2A46G2T/P-IZSY/ANPR

IP camera Hikvision DS-2CD2A46G2T/P-IZSY/ANPR 2.7-13.5 PL(POL)

AcuSense 4 MP bullet-type zoom network camera

• Support for Hikvision Embedded Open Platform (HEOP) and the ability to install third-party applications
• Supports 1,5 Tops processing power, 60 MB system memory, 400 MB intelligent RAM and 2 GB eMMC memory for resource sharing
• High-quality image in 4MP resolution
• Superior low-light performance with Powered-by-DarkFighter technology
• Powerful H.265+ compression technology
• Clear imaging in case of strong taillight thanks to true WDR 120 dB technology
• Accurate classification of human/vehicle alarms based on deep learning algorithms.
• Built-in alarm and audio interfaces
• 3D DNR technology for clear and sharp images
• Motorized zoom lens for easy installation
• Water and dust resistance (IP67) and vandal resistance (IK10)

Hikvision – ANPR cameras for automatic license plate recognition

ANPR cameras by Hikvision are advanced solutions for automatic license plate recognition, used in many sectors – from traffic management, through access control, to parking systems and Smart City infrastructure. Thanks to deep learning technology, the devices achieve recognition efficiency of ≥ 98%, recording not only the boards, but also the characteristics of the vehicle, such as type, color, make and direction of travel.

Hikvision ANPR cameras work reliably in all conditions – day and night, in low light, rain or snow. They handle multiple lanes and high-speed vehicles, providing precise real-time data. The open architecture with ONVIF and API support allows for easy integration with external systems, making them a versatile tool for automating and improving security in public and private spaces.

HIK-CONNECT APPLICATION

Hik-Connect mobile application, enables remote management of products. Hik-Connect also provides a login mode where you can manage your devices without registering. Once you install the app on your phone, you can access your devices via Wi-Fi, 3G or 4G. G

Hikvision DarkFighter — monitoring that is not afraid of the dark

DarkFighter is a night vision technology from Hikvision, allowing you to capture colorful and sharp images even with minimal light intensity (up to about 0,0003 lux), without the need for additional lighting.

Ideal for use where discretion or limited lighting is required – e.g. parking lots, warehouses, parks or industrial areas. The technology extends the runtime without additional light, automatically activating it only when needed.

DarkFighter is an elegant combination of brightness, sharpness and discretion – ideal for professional night monitoring.

Hikvision DarkFighter technology – monitoring that sees in the dark

DarkFighter is an advanced image processing technology from Hikvision, designed for effective monitoring in very low light conditions. DarkFighter cameras capture colored, clear images even at night, without the need for intense outdoor lighting.

• High sensitivity – image detection with a minimum level of light (even below 0.005 lux),
• Bright lens (e.g. F1.0/F1.2) – allows for greater light flow to the sensor,
• Large image sensor (e.g. 1/1.8") – more details and less noise,
• Advanced noise reduction algorithms and WDR – better contrast and detail in harsh environments.

DarkFighter is a proven solution for demanding vision systems, where night vision quality is crucial.

Technical Specifications

• Model: DS-2CD2A46G2T/P-IZSY/ANPR2.7-13.5(POL)
• Image Sensor: 1/3" Progressive Scan CMOS
• Max. Resolution: 2688 × 1520
• Min. Illumination: Color: 0.003 lux @ F1.4 (AGC ON); B/W: 0 lux with IR
• Shutter Speed: 1/3 s to 1/100,000 s
• Camera Position Adjustment: Pan: 0–355°, Tilt: 0–90°, Rotation: 0–360°
• Day/Night Mode: IR Cut Filter
• Lens Type: Varifocal, 2.7–13.5 mm Motorized Zoom
• Focal Length & Field of View: 2.7–13.5 mm; H: 107.6°–32.9°, V: 50.5°–18.5°, D: 130.9°–37.8°
• Lens Mount: Ø14
• Aperture Type: Auto-iris
• Aperture: F1.6
• DORI - Detect: 64–187 m (2.7–13.5 mm)
• DORI - Observe: 25–74 m (2.7–13.5 mm)
• DORI - Recognize: 12–37 m (2.7–13.5 mm)
• DORI - Identify: 6–18 m (2.7–13.5 mm)
• Additional Illumination Type: IR
• IR Illuminator Range: Up to 60 m
• Smart IR: Yes
• IR Wavelength: 850 nm
• Memory: Flash: 60 MB; RAM: 400 MB; eMMC: 2 GB
• Processing Power: 1.5 TOPS
• Open Capabilities: HEOP 2.0, OpenSDK
• Deep Learning Frameworks: Caffe, PyTorch, TensorFlow, PaddlePaddle, ONNX
• Programming Languages: C, C++
• Main Stream: 50 Hz: 25 fps (2688×1520, 1920×1080, 1280×720); 60 Hz: 30 fps (2688×1520, 1920×1080, 1280×720)
• Sub-stream: 50 Hz: 25 fps (1280×720, 640×480, 640×360); 60 Hz: 30 fps (1280×720, 640×480, 640×360)
• Third Stream: 50 Hz: 10 fps; 60 Hz: 10 fps (1920×1080, 1280×720, 640×480, 640×360)
• Fourth Stream: 50 Hz: 10 fps; 60 Hz: 10 fps (1280×720, 640×480, 640×360)
• Video Compression: Main: H.265/H.264/H.264+/H.265+; Sub-stream: H.265/H.264/MJPEG; Third: H.265/H.264; Fourth: H.265/H.264/MJPEG
• Video Bitrate: 32 Kbps – 8 Mbps
• H.264 Type: Baseline Profile, Main Profile, High Profile
• H.265 Type: Main Profile
• Bitrate Control: CBR / VBR
• Scalable Video Coding (SVC): H.264 and H.265 encoding
• Target Cropping: Yes
• ROI: Supports 5 fixed regions for main stream and sub-stream
• e-PTZ: Supports patrol settings and auto-tracking
• Audio Compression: G.711u, G.711a, G.726, MP2L2, PCM, MP3, AAC-LC
• Audio Bitrate: 64 Kbps (G.711u/G.711a); 16 Kbps (G.722.1); 16 Kbps (G.726); 32–192 Kbps (MP2L2); 8–320 Kbps (MP3); 16–64 Kbps (AAC-LC)
• Audio Sampling Rate: 8 kHz / 16 kHz / 32 kHz / 44.1 kHz / 48 kHz
• Environmental Noise Filtering: Yes
• Network Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SFTP, ARP, SNMP, WebSocket, WebSockets, SRTP
• Simultaneous Live View: Up to 6 channels
• API: ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
• Users/Hosts: Up to 32 users
• User Levels: Administrator, operator, user
• Security: Password protection, complex passwords, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, WSSE, RTP/RTSP over HTTPS, control timeout, audit log, TLS 1.1/1.2/1.3, host authentication (MAC)
• Storage: NAS (NFS, SMB/CIFS), ANR, supports microSD card with encryption and verification
• Client Software: iVMS-4200, Hik-Connect, Hik-Central
• Web Browser: Live View: IE 10/11; Plug-in free: Chrome 57+, Firefox 52+, Edge 89+; Local service: Chrome 57+, Firefox 52+, Edge 89+
• Image Parameter Switching: Yes
• Image Settings: Corridor mode, saturation, brightness, contrast, sharpness, gain, white balance
• Day/Night Switch: Day, night, auto, schedule
• WDR: 120 dB
• Image Quality Enhancements: BLC, HLC, 3D DNR, Defog
• SNR: ≥ 52 dB
• Privacy Mask: 4 programmable polygonal masks
• Ethernet Interface: 1 × RJ-45 10/100 Mbps self-adaptive port
• Memory Card Slot: microSD / microSDHC / microSDXC up to 512 GB
• Alarm: 1 input, 1 output (max. 24 VDC / 24 VAC, 1 A)
• Reset: Yes
• Audio Input: 1 input (line level), 2-pin terminal, max. 3.3 Vpp amplitude, 4.7 kΩ impedance, unbalanced interface
• Audio Output: 1 output (line level), 2-pin terminal, max. 3.3 Vpp amplitude, 100 Ω impedance, unbalanced interface
• Power Output: 12 VDC, max. 100 mA
• Communication Protocol: 1 × Wiegand (CardID 26 bit, SIA-A 26 bit, Hik 34 bit, NEWG 72 bit)
• Basic Events: Motion detection (human/vehicle), tamper alarm, video exception
• Smart Event: Scene change detection, unusual audio detection, defocussing detection
• Event Linking: FTP/NAS/memory card, CMS notifications, email, alarm output, recording, snapshot, audible warning
• Face Capture: Yes
• Person Detection: Yes
• Perimeter Protection: Line crossing, intrusion, region entrance/exit; classification: human/vehicle
• Traffic and Vehicle Detection: Up to 100,000 black/white lists for vehicles
• License Plate Recognition (LPR): Supports LPR; accuracy ≥ 95%
• Motorcycle License Plate Recognition: Supported (checkpoint scenario only)
• Power Supply: PoE IEEE 802.3at, Class 4, max. 15 W
• Dimensions: Ø105 × 332.8 mm (Ø4.1" × 13.1")
• Package Dimensions: 385 × 190 × 180 mm (15.2" × 7.5" × 7.1")
• Weight: Approx. 1485 g (3.27 lb)
• Weight with Package: With "eF" bracket: Approx. 2464 g (5.43 lb); Without "eF" bracket: Approx. 2304 g (5.08 lb)
• Storage Conditions: −30°C to +60°C; humidity ≤ 95% (non-condensing)
• Operating Conditions: −30°C to +60°C; humidity ≤ 95% (non-condensing)
• General Functions: Heartbeat, anti-banding, mirror, flash log, password reset via email, pixel counter
• Language: Polish
• Certificates / EMC: CE-EMC: EN 55032:2015+A1:2020; EN 50130-4:2011+A1:2014; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; RCM AS/NZS CISPR 32:2015; IC ICES-003 Issue 7; KC KN32:2015, KN35:2015
• Safety: CB IEC 62368-1:2014+A11; CE-LVD EN 62368-1:2014/A11:2017; BIS IS 13252 (Part 1):2010 / IEC 60950-1:2005; LOA IEC/EN 60950-1
• Environment: CE-RoHS 2011/65/EU; WEEE 2012/19/EU; REACH (EC) No 1907/2006
• Protection Level: IP67 (IEC 60529:2013); IK10 (IEC 62262:2002)
• Corrosion Protection: -Y, NEMA 4X (NEMA 250-2018)
