Dyzelinio variklio kompresijos matuoklis

Trumpai apie prekę

Prekė: Dyzelinio variklio kompresijos matuoklis. Kategorija: Slėgio jutikliai.

• Gamintojas: Magma
• Modelis: 1011G

Tester designed to measure the degree of compression in cylinders of diesel engines with direct and indirect injection. Double graduated pressure gauge Bar and PSI equipped with control valve for control purposes.

For engines of passenger cars, vans and smaller trucks.

• Pressure gauge with a range of 0 - 70 bar / 0 - 1000 LB/SQ.IN with a diameter of 80 mm.
• Flexible cable length 400 mm equipped on both sides with a metal flexible spiral, which prevents the cable from breaking. The hose is also terminated with a functional quick coupler that facilitates the insertion of individual measuring tips as well as a valve that prevents the manometer hand from retracting before the measurement is completed.
• Auxiliary beam for yoke-mounted ends.
• Elbow adapter with quick release.
• Spare set of gaskets and valves.
• Tips - measuring adapters.

- Thread tip M10 x 1.25 - glow plug

- M12 x 1.25 thread tip

- glow plug (Opel. Peugeot. Mercedes. VW. Ford. seats. Fiat. Renault.

Citroen. Peugeot. Land Rover)

- Thread tip M24 x 2 - injector (VW. Audi . Mercedes. Opel. Peugeot)

- thread tip M20 x 1.5 - injector

- M10 x 1 thread tip - LAND ROVER glow plug

- Tip mounted on the jażmo - STANADYNE glow plug

- tip attached to the hedgehog - DL injector

- Thread tip M10 x 1.25 - glow plug long

- Measuring tip M14 x 1.25 - glow plug

ADAPTERS:

• Thread tip M10 x 1,25 – glow plug
• Thread tip M12 x 1,25 – glow plug (Opel, Peugeot, Mercedes, VW, Ford, Seat,
• Fiat, Renault, Citroen, Peugeot, Land Rover)
• Thread tip M24 x 2 – injector (VW, Audi, Mercedes, Opel, Peugeot)
• Thread tip M20 x 1,5 – injector
• Thread tip M10 x 1 – LAND ROVER glow plug
• Tip mounted on jażmo – STANADYNE glow plug
• Jażmo-mounted tip – DL injector
• Thread tip M10 x 1,25 – long glow plug
• Measuring tip M14 x 1,25 – glow plug

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Brand	Magma
Parametry	Product weight with unit packaging	4 kg
Parametry	EAN (GTIN)	5903246820331
Parametry	Manufacturer code	1011G
