Belaidis prieigos taškas TP-LINK TL-EAP650-DESKTOP, Wi-Fi 6

Trumpai apie prekę

Prekė: Belaidis prieigos taškas TP-LINK TL-EAP650-DESKTOP, Wi-Fi 6. Kategorija: WiFi maršrutizatoriai ir prieigos taškai.

• Gamintojas: TP-Link
• Modelis: 569540248

EAP650-Desktop

New

• Wi-Fi 6 AX3000: 574 Mbps in the 2,4 GHz band and 2402 Mbps in the 5GHz band, offering a total of up to 2976 Mbps Wi-Fi†
• Gigabit Ports: Connect multiple devices using 4 gigabit Ethernet ports
• Practical deployment: Support 802.3bt PoE++ and DC power supply (power supply included) for easy and fast deployment
• No installation required: Connecting the device does not require additional installation
• High flexibility: The device can be mounted on a desk or wall
• Advanced features: Omada Mesh, Smooth roaming and Centralized cloud management

Certificates: CE, FCC, RoHS, IC

Content of the package:

• EAP650-Desktop

• Desk/wall mount kit

• Installation instructions

System requirements:

Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux

Working environment:

• Permissible operating temperature: 0℃–40℃ (32℉–104℉)

• Permissible storage temperature: -40℃–70℃ (-40℉–158℉)

• Permissible air humidity: 10%–90%, non-condensing

• Permissible storage humidity: 5%–90%, non-condensing

Desk Mount: No additional installation required

Wall Mount: Space-Saving

Ports: 4 Ethernet ports 1Gb/s

1 port FXS

1 Ethernet port supports PoE output: 802.3at/af using 802.3bt or 802.3af class 2 input using 802.3at input

Buttons: Reset

LED

Power supply: 802.3 af/at/bt PoE or 12V/1,5A DC

*PoE output requires PoE 802.3at/bt power

Power Consumption: 17,3W (PoE Output Off)

Weight: 452g (without mounting stand)

Dimensions (S x G x W): 175 × 140 × 33 mm

Antenna Type: Internal, Omnidirectional

• 2,4 GHz: 2× 5 dBi

• 5 GHz: 3× 4,7 dBi

Range: 140m2 *

Mounting: On desk/wall (mounting kit included)

Number of simultaneous clients: 250+*

Wireless standards: IEEE 802.11 a/b/g/n/ac/ax

Operating frequency: 2,4 GHz and 5 GHz

Transmission speed:

• 5 GHz: 2402 Mbps†

• 2,4 GHz: 574 Mbps

Wireless transmission functions:

• 2×2 (2,4GHz and 5GHz) MU-MIMO‡

• HE160 (160 MHz channel width)‡

• OFDMA‡

• Omada Mesh

• Smooth roaming §

• Multi SSID (16 SSID, 8 for each band)

• Enable/Disable SSID broadcasting

• Enable/Disable Wireless Transmitter

• Guest Network

• Automatic channel selection

• Beamforming

• Speed limit (based on SSID/Customer)

• Band control

• Bandwidth load balancing

• Airtime Fairness

• Transmission power control (power adjustment based on dBm)

• QoS (WMM)

• RADIUS Accounting

• MAC authentication

• Restart schedule

• Wireless network schedule and statistics

• Static/Dynamic IP address

Wireless transmission security:

• Authentication via the welcome page§

• Access control

• Filter wireless MAC addresses

• Isolation of wireless-connected clients

• VLAN

• Detection of unauthorized APs

• Support 802.1X

• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

Power of transmission:

• CE:

< 20 dBm(2,4 GHz, EIRP)

< 23 dBm(5 GHz, band 1 and band 2, EIRP)

< 29 dBm(5 GHz, band 3, EIRP)

Omada App: Yes

Central management:

• Omada hardware controller

• Omada software controller

• Cloud-based Omada Controller

Cloud Access: Yes

Diode Switch: Yes

MAC Address Access Control: Yes

SNMP: v1, v2c, v3

System Log: System Log

SSH: Yes

Browser Management: Yes

Maintenance-free ZTP configuration: Yes. Requires the use of a cloud-based Omada controller.

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer	TP-Link
Parametry	Mode of operation	Access Point
Parametry	Internal modem	no modem
Parametry	LAN port operating standard	10/100/1000 Mbps
Parametry	EAN (GTIN)	5908066819299
Parametry	Manufacturer code	569540248
Parametry	Model	569540248
Parametry	The highest standard supported	802.11ax (Wi-Fi 6)
Parametry	Wireless operation standard	802.11ax (Wi-Fi 6),802.11ac (Wi-Fi 5),802.11n (Wi-Fi 4),802.11g,802.11b,802.11a
