Belaidis prieigos taškas TP-LINK EAP225 AC1350, PoE, 802.11a/b/g/n/ac

Trumpai apie prekę

Prekė: Belaidis prieigos taškas TP-LINK EAP225 AC1350, PoE, 802.11a/b/g/n/ac. Kategorija: WiFi maršrutizatoriai ir prieigos taškai.

• Gamintojas: TP-Link
• Modelis: EAP225EA

Access point Tp-Link EAP225 Access Point AC1350 POE 802.11a/b/g/n/ac

✅ Operation in 2,4 and 5 GHz bands simultaneously

✅ 1x Gigabit Ethernet port

✅ 2x2 MU-MIMO technology

✅ Compatibility with EAP Controller software

✅ Power supply via PoE (802.3af or passive)

✅ Authentication via welcome page, via Facebook and SMS

✅ Airtime Fairness

✅ Directional transmission

✅ Bandwidth control

✅ Reset button

✅ Kensington Security

TP-Link EAP225

TP-Link EAP225 is a gigabit, wireless ceiling-mountable access point, AC1350

Its maximum theoretical WiFi bandwidth is 1317 Mbps (450 Mbps in the 2,4 GHz band and 867 Mbps in 5 GHz), allowing you to work in both bands simultaneously. It supports IEEE 802.11 b/g/n and IEEE 802.11 a/n/ac standards and is compatible with EAP Controller software.

The EAP225 features a gigabit Ethernet port, as well as three omnidirectional internal antennas with an energy gain of 4 dBi (2,4 GHz) and two 5 dBi (5 GHz). The device uses MU-MIMO technology, allowing simultaneous sending and receiving of data from multiple connected devices, which significantly improves the operation of the wireless network.

EAP Controller software

EAP Controller software allows you to centrally manage multiple access points. It makes it much easier to set up and expand networks, even in multiple locations. Thanks to it, you can remotely update software on connected devices, monitor work in real time or plan a wireless network by visualizing the range. It also allows you to create a unique hotspot welcome page and introduce various types of authentication (e.g. by Facebook or SMS). The software is completely free.

Identification of guests via Facebook and SMS

Authenticating wireless clients through the welcome page is extremely convenient. This method requires the user to perform appropriate actions (such as e.g. Approval of the terms of use or logging into the system) in order to gain access to the network. These actions are then authenticating wireless clients through the welcome page is extremely convenient. Support for Facebook and SMS authentication makes it even easier for customers to access your network and creates additional opportunities for your business.

Ease of installation and PoE power supply

Modern design and ease of installation allow for seamless adjustment of the device to any interior. The EAP225 supports both PoE 802.3af and passive PoE, allowing you to quickly and conveniently mount your device without the need for additional cables.

Wireless transmission functions

Multi-SSID （Up to 16 SSID, 8 for each band), Wireless Network Shutdown, Automatic Channel Selection, Transmission Power Control, QoS(WMM), Seamless Roaming, Bandwidth Control, Band Load Balancing, MU-MIMO, Airtime Fairness, Beamforming, Bandwidth Control, Reset Schedule, Wireless Network Schedule, SSID/Wire Statistics

Unmatched AC-WLAN speed with MU-MIMO technology

The latest generation of 802.11ac Wi-Fi, combined with 2*2-MU-MIMO, enables unprecedented speeds and ranges of up to 1317 Mbps.

Multiple PoE options for easy installation

The EAP225 supports both 802.3af PoE and passive PoE power. It can be powered by a PoE switch or PoE adapter, making installation easy and flexible.

High performance with a large number of guests

Breakthrough Wi-Fi speeds, ease of installation, power via PoE, management software, welcome page authentication, security and business-class components make EAP devices great for the most demanding environments, such as e.g. schools, hotels and large companies.

Intelligent network connections

Thanks to intelligent network transmission via 802.11k/802.11v, the connection to the access point is automatically transmitted with an optimal signal. This enables uninterrupted voice, video conferencing or large amounts of data.

Central Wi-Fi management - anytime, anywhere

Cloud management software acts as an access controller and allows you to centrally control several hundred individual devices. This makes it easier to set up tasks such as setting up, updating firmware, and monitoring Wi-Fi devices on your network in real time.

Even more practical with the Omada app

Through your smartphone you have convenient access and the ability to configure wherever you are.

Technical data:

• Operating mode - Access Point
• Types of inputs/outputs - RJ-45 10/100/1000 (LAN - PoE) - 1 pc.
• Supported standards - Wi-Fi 5 (802.11 a/b/g/n/ac), 802.3 af (PoE)
• Operating frequency - 2,4 GHz, 5 GHz
• Antenna - Internal - 4 pcs.
• Maximum wireless transmission speed - 1350 Mbps
• Wireless transmission security - 64/128-bit WEP, WPA, WPA-PSK, WPA2-PSK, WPA2 Enterprise
• Management and configuration - Website, SNMP
• Power supply - Power supply, PoE
• Additional information - Reset button, Kensington security
• Included Accessories - PoE Adapter, Mounting Kit

Specifications
