Komutatorius Netgear GS108E, 8 jungčių, 2 vnt., Gigabit Ethernet, valdomas, QoS, VLAN

Trumpai apie prekę

Prekė: Komutatorius Netgear GS108E, 8 jungčių, 2 vnt., Gigabit Ethernet, valdomas, QoS, VLAN. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: 8level
• Modelis: GES-8D

• Ports: 8x 1000 Mbps
• Metal housing
• Wall Mount
• ProSAFE Plus - network monitoring
• Simple plug-and-play installation
• Support for VLANs
• Quality of Service (QoS)
• Protection against DoS
• Wiring test
• Protection against loops and broadcast storms
• IGMP snooping v1, v2 and v3
• Capacity limitation
• Port mirroring
• Support Jumbo frames

Modern, growing companies need and rely on networks more and more, performing tasks critical to the mission of their company. However, companies may not have the budget or specialized training necessary to deal with complex managed switches. NETGEAR ProSAFE® Plus switches meet this growing need by providing essential networking features to help optimize the performance of your corporate networks. In addition to plug-and-play Gigabit Ethernet connectivity, these switches also offer basic networking features such as VLAN, QoS, IGMP Snooping, Link Aggregation (LAG), speed limiting and traffic monitoring.

With the ability to configure QoS, Gigabit Plus switches can detect different types of network traffic and assign the desired priority to time-sensitive traffic, such as voice and image transmissions. This helps improve the output quality of related applications such as VoIP, multimedia content broadcasting and video conferencing.

Gigabit Plus switches can help you divide large networks into smaller, more manageable groups to which you can assign selected resources, rather than making them available to all users. This feature improves overall network performance, increases network traffic security, and allows you to use available network resources more efficiently.

All Gigabit Plus switches are equipped with a cable diagnostic function that allows users to easily check the status of network cables. In the event of any problem, this feature helps you quickly locate the cable failure point and remove the fault much faster, potentially saving many hours of service technician work.

By listening for IGMP communication between hosts and routers, the Gigabit Plus switch can create a map that determines which links need which multicast streams. The Gigabit Plus switch will thus be able to transmit multicast traffic only to links that report such demand. The most important advantage of the IGMP protocol is that it helps optimize multicast transmission performance at Layer 2. This is especially useful for multicast IP applications that use available bandwidth intensively, such as IPTV.

• Auto-negotiation of port parameters
• 801.2x Flow Control
• DHCP Client
• Dynamic MAC address management
• IEEE802.1Q
• WRR, strict priority
• IEEE801.2p
• ToS (Type-of-Service)
• DSCP (GS105E and GS105PE only)
• Capacity limitation
• Connection linking (feature available on models with at least 16 ports)

• IGMP snooping, v1, v2 and v3
• IGMP Snooping querier (models 16 and 24 ports)
• Blocking unknown multicast traffic

• Port mirroring on input/output
• Jumbo frames
• Broadcast Storm Control
• Diagnostics of wiring
• Loop detection
• Protection of DoS
• Energy Efficient Ethernet (IEEE802.3az) (selected models)

• Application for PC Plus
• Firmware upgrade via Plus app (TFTP)
• Password protection

• Gigabit ports: 8
• MAC board: 4K
• Buffer size: 192KB
• VLAN: 32
• Mulitcast groups: 128
• Power supply: External - 12V/1A
• Maximum energy consumption (Watt): 4
• MTBF: 5701574 hours
• Weight (kg): 0.55
• Dimensions (WxDxH) mm: 158x105x27

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer	8level
Parametry	Product weight with unit packaging	0.6 kg
Parametry	Number of ports	8
Parametry	Number of LAN (RJ-45) ports	8
Parametry	EAN (GTIN)	5904268090221
Parametry	Manufacturer code	GES-8D
Parametry	Certificates of conformity	CE,WEEE
