Lieferzeit in ganz Litauen: 5-10 Werktage
Lieferpreis an die angegebene Adresse: 3 Euro
Trumpai apie prekę
Prekė: 5 jungčių PoE komutatorius su maitinimo rezervu ATTE IPUPS-5-11-XL2. Kategorija: Jungikliai ir koncentratoriai.
- Gamintojas: Atte
- Modelis: IPUPS-5-11-XL2
Model: IPUPS-5-11-XL2
TECHNICAL DATA
- Total number of ports: 5 PoE ports, 1 UpLink port
- PoE ports OUT: LAN 1 ... LAN 5 PoE Passive
- PoE IN/OUT ports: LAN 5 PoE Passive
- LAN ports 10/100Mbps: LAN 1 ... LAN 6
- LAN + PoE ports OUT 10/100Mbps: LAN 1 ... LAN 5
- LAN Long Range ports: LAN 1 ... LAN 4 - 10Mbps range up to 280 m
- Input voltage: 190 ... 260 VAC, 50 Hz
- PoE output voltage: 48 VDC +/- 2%
- Maximum output power from port: PoE Passive LAN 1 ... LAN 4 - 40 W, LAN 5 - 60 W
- Power control at the output: PoE ON/OFF switch - positions 2...6 (LAN 1...LAN 5)
- Overvoltage protection: LAN 1 ... LAN 6
- Overload protection: LAN 1 ... LAN 4 Overload protection 0,75A LAN 5 Overload protection 1,25A
- Power Supply Type: Buffer SMPS
- Power supply - continuous: 72 W
- Efficiency: 90% @60 W
- Power supply input protection: Fuse fuse immediate 3,15 A
- Power supply output protection: Electronic overload protection at 9 A
- Power supply thermal protection: TSD 130°C - requires power supply restart
- Battery circuit protection: Battery disconnection for voltage below 10,8 V Fuse fuse 6,3 A
- Starting in the absence of AC power: START button
- Battery charging current: 1 A or 2 A
- Battery: Gel or AGM 12V/7Ah
- Voltage signaling from the mains: LED_AC (yellow) - presence of mains voltage
- Output voltage signaling: LED 1 (green) - presence of output voltage
- Battery signal: LED 2 (red) - battery charging
- PoE signaling: LED LAN 1 ... LAN 5 (red) - presence of PoE power supply
- Transmission signal: LED LAN 1 ... LAN 6 (green) - link and data transmission
- Operating temperature range: -25°C ... +50°C
- Dimensions (S x W x G): 220 x 300 x 120 mm
- Weight: 1,64 kg
- Degree of protection: IP56
- Housing: ABOX-XL1 / plastic / grey / glands 5 x M16, 1 x M20
- Assembly: Wall-mounted, mounting brackets
- EAN code: 5902143690429
- PKWiU code: 26.30.23.0
- HS code: 8517 62
- CN2020 code: 8517 62 00
Specifications
| Group | Name | Value |
|---|---|---|
| Parametry | Condition | new |
| Parametry | Invoice | With VAT invoice |
| Parametry | Manufacturer | Atte |
| Parametry | Product weight with unit packaging | 1.68 kg |
| Parametry | Number of ports | 6 |
| Parametry | EAN (GTIN) | 5902143690429 |
| Parametry | Manufacturer code | IPUPS-5-11-XL2 |
| Parametry | Packaging status | original |
| Parametry | Certificates of conformity | CE,WEEE |
